R911285448 (MHD112B-058-NP0-AN)

Name: R911285448 (MHD112B-058-NP0-AN)
Brand: Indramat Motors
SKU: MHD112B-058-NP0-AN
Price: 721.00 USD
Availability: InStock
Rating: 4.5 (10 reviews)

MHD Synchronous Motors

Rated 4.5 stars (10 total reviews)

Front Left

In-Stock, Ships 3-5 Days

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone

Part Number

+Add a message

Message

Request a Replacement

Request a Repair

Quote Both

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Current response time:

6 Minutes 42 Seconds

Phone:
1-888-551-3082

Email:
sales@indramat-usa.com

The Bosch Rexroth R911285448 (MHD112B-058-NP0-AN) is a synchronous servo motor designed for high-performance applications requiring precise control and reliable torque output. It features digital servo feedback (HSF) for relative position detection and is equipped with a stator winding optimized for effective heat dissipation. The motor has a continuous standstill torque of 28.0 Nm and incorporates a keyed shaft with a shaft seal and liquid cooling. Other specifications include a housing with IP65 ingress protection, a flange size of 192 mm, centering diameter of 130 mm, motor size 112, motor length B, winding code 058, output connector for power connection to side A, and operation without a holding brake. Maximum installation elevation is 1000 meters above sea level.

Technical Specifications

Torque Output
Optical for entire speed range

Maintenance
Maintenance free operation

Electronic Commutations
Available, replaces motor brushes

Ingress Protection Standard
IP 65

Installation Elevation
Maximum 1000 meters above sea level

Global Shipping
Available

Frequently Asked Questions

What shaft design is used in the MHD112B-058-NP0-AN motor?

The MHD112B-058-NP0-AN motor has a keyed shaft.

What encoder does the MHD112B-058-NP0-AN motor use?

The MHD112B-058-NP0-AN uses digital servo feedback (HSF).

Does the MHD112B-058-NP0-AN motor include a brake?

No, the MHD112B-058-NP0-AN motor does not have a holding brake.

What torque at standstill does the MHD112B-058-NP0-AN motor deliver?

The MHD112B-058-NP0-AN motor delivers 28.0 Nm torque at standstill.

Which cooling method is applied to the MHD112B-058-NP0-AN motor?

The MHD112B-058-NP0-AN motor uses liquid cooling.

Common Misspellings

MHD 112B 058 NP0 AN

MHD 112B-058-NP0-AN

MHD-112B-058-NP0-AN

MHD112B-O58-NPO-AN

MHD112B058NP0AN

MHDII2B-058-NP0-AN

MHD112B 058 NP0 AN

mhd112b-058-np0-an

Internal Product Review

The MHD112B-058-NP0-AN is widely regarded as a dependable solution for operators. Customers find it provides smooth performance, helping to maintain productivity. Its consistent operation supports ongoing use with confidence. Many value its reputation for reliability, making it a strong choice for those who require efficient and practical performance in everyday applications.
