R911286826 (MHD112C-058-PP0-AN)

MHD Synchronous Motors

In Stock, Ships Today

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone

Part Number

+Add a message

Message

Request a Replacement

Request a Repair

Quote Both

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone:
1-888-551-3082

Email:
[email protected]

The MPN R911286826 (MHD112C-058-PP0-AN) is a synchronous servo motor from the MHD series, designed for use in digital drive controllers in applications such as machine tools and automation. It features a stator, rotor, bearings, encoder, and a keyed shaft with shaft seal. This model is equipped with absolute digital feedback via an integrated multiturn encoder (>4096 revolutions). The motor delivers a continuous standstill torque of 38.0 Nm (value varies with cooling), operates without a holding brake, and supports liquid cooling. The housing conforms to IP65, has a centering diameter of 130 mm, a flange size of 192 mm, and a motor length coded as C. The power output connector is oriented to side A, and the winding code is 058. The motor can operate up to 4500 RPM, at temperatures from 0 to 40°C, and elevations up to 1000 m with class F insulation. Total weight is 45 kg.

Technical Specifications

Design
Closed

Rating
IP65

Components
Stator, Rotor, Bearings, Encoder, Shaft

Holding Brake
No

Housing Cooling
Natural Convection/Surface Cooling

Ambient Temperature Range
0-40 degrees Celsius

Power Connector Location
Side A

Shaft Elements
Key and Sealing Ring

Encoder
Integrated Multiturn

Servo Feedback
Digital

Characteristic Speed
4000 RPM

Max Speed
4500 RPM

Rated Speed (60K overtemperature, natural convection)
2000 RPM

Rated Speed (100K overtemperature, natural convection or surface cooling)
3500 RPM

Continuous Stall Torque (60K overtemperature, natural convection)
38 Nm

Continuous Stall Torque (100K overtemperature, natural convection)
43.5 Nm

Continuous Stall Torque (Surface cooling)
57 Nm

Liquid Cooling
Not Available

Weight
45 kilograms

Max Setup Height
1000 meters above sea level

Insulation Class
F (DIN VDE 0530 Part 1)

Surface Finish
Prime Black Coat

Frequently Asked Questions

What advantages does the digital servo feedback with integrated multi-turn absolute encoder (>4096 revolutions) on the MHD112C-058-PP0-AN provide for homing and restart sequences?

The multi-turn absolute system retains position across power cycles for eliminating homing moves and fixtures after restarts. Its higher-resolution feedback improves loop gain, reduces following error and eases disturbance rejection in fast axes.

How do the 130 mm centering diameter and 192 mm flange interface affect mounting concentricity, stiffness, and coupling alignment in precision assemblies?

The standardized spigot and flange establish radial datum and bolt-pattern rigidity for reducing eccentricity and axial wobble at the motor–machine interface. Its better concentricity simplifies coupling alignment and maintains encoder-to-load correlation at high speeds.

Why is a keyed, sealed shaft specified on the MHD112C-058-PP0-AN, and which coupling styles best exploit that geometry?

The key transmits torque without relying solely on friction and the seal limits ingress of coolant and contaminants. Its zero-backlash clamp-hub or elastomer jaw couplings maintain alignment while damping torsional ripple.

How does the power connection orientation to side-A on the MHD112C-058-PP0-AN influence cable routing and electromagnetic compatibility inside compact gantry enclosures?

The side-A connectors shorten cable runs and allow separation from feedback harnessing for easing EMC management and bend-radius constraints. Its predictable exit direction simplifies strain relief, drag-chain layouts and maintenance access.

What maintenance and environmental points follow from the sealed construction and liquid-cooled housing common to the MHD series?

Its sealed bearings and housings minimizes lubrication tasks, while coolant quality and flow verification dominate preventive checks. Its proper filtration prevents fouling for ensuring thermal performance and encoder stability across multi-shift operation.

Common Misspellings

Internal Product Review

Rexroth Indramat manufactures the servo motor MHD112C-058-PP0-AN in a 112 size 112 and length C mechanics. It uses liquid cooling and possesses an absolute multi-turn encoder for feedback. This unit is accompanied by a keyed, sealed shaft and side-A connector for simplifying integration. It is rated for 38 Nm torque at standstill that makes it fits into CNC axes, robotics and packaging lines.
