R911286976 (MHD093B-035-NG0-AA)

MHD Synchronous Motors

In Stock, Ships Today

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone

Part Number

+Add a message

Message

Request a Replacement

Request a Repair

Quote Both

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone:
1-888-551-3082

Email:
[email protected]

The R911286976 (MHD093B-035-NG0-AA) is a synchronous servo motor designed for use in industrial automation. It operates at a nominal speed of 2500 rpm and provides a rated power range of 2.7 to 6.6 kW. The motor features digital servo feedback (relative position detection) and natural convection housing cooling. It accepts an input AC voltage of 350 to 374 V at a rated operating frequency of 167 Hz and a continuous current of 4.6 to 10.8 A, producing a torque output between 8.8 and 20.9 Nm, with a continuous standstill torque of 17.5 Nm. The unit uses a plain shaft with seal, flange sizes of 140/150 mm, a centering diameter of 130 mm, and is sized as motor 093 with motor length B. It offers IP65-rated protection and is designed to operate in temperatures from 0 to +40°C, up to 1000 m altitude. Power connection is on side A via output connector. The model does not include a holding brake and uses the 035 winding code.

Technical Specifications

Product Type
Synchronous Motor

Mounting Position
IMB5, IMV1, IMV3

Flange Design
B05

Flange Size
140/150 mm

Centering Diameter
130 mm

Feedback Mechanism
Digital Servo

Rated Power
2.7 – 6.6 kW

Nominal Speed
2500 rpm

Rated Voltage
350 – 374 V

Operating Frequency
167 Hz

Protection Category
IP65

Power Connector Position
A-side

Rated Current
4.6 – 10.8 A

Continuous Current Torque
8.8 – 20.9 Nm

Thermal Time Constant
30 – 60 min

Number of Pole Pairs
4

Ideal Operating Temperature
0 to +40 degree Celsius

Maximum Setup Height
1000 meters above sea level

Frequently Asked Questions

Common Misspellings

Internal Product Review

The MHD093B-035-NG0-AA is known for its stable performance during extended activities. Its structure allows easy implementation within various frameworks. Reliability defines its behavior across applications. Many installations benefit from its predictable function. The unit fits well into different system configurations. It is trusted for dependable operation.
