R911286979 (MHD093B-035-NP1-AN)

MHD Synchronous Motors

In Stock, Ships Today

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone

Part Number

+Add a message

Message

Request a Replacement

Request a Repair

Quote Both

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone:
1-888-551-3082

Email:
[email protected]

The R911286979 (MHD093B-035-NP1-AN) is a digital feedback servo motor designed for integration with drive controllers to regulate speed and position. It features a holding brake with 22 Nm torque, a keyed shaft with sealing ring, and a power connector on side A. The motor supports natural convection or surface cooling, has an IP65-rated housing, a frame size of 093, length B, moment of inertia of 0.00255 kg·m², and delivers a maximum theoretical torque of 66 Nm with a max speed of 4500 RPM. Suitable operation is between 0 to 40°C, up to 1000 meters altitude, with storage from -20 to 80°C. Minimum recommended wire size is 1.5 mm².

Technical Specifications

Motor Feedback
Digital Servo Feedback

Holding Brake Available
Yes

Brake weight
1.1 kilograms

Brake Holding Torque
22 Nm

Brake Rated Voltage
24 Volts DC

Brake Rated Current
0.71 Amps

Brake Connection Time
25 milliseconds

Brake Disconnection Time
50 milliseconds

Motor Frame Size
093

Frame Length
B

Moment of Inertia
0.00255 kg m2

Maximum Theoretical Torque
66 Nm

Time Constant
60 minutes

Maximum Speed
4500 RPM

Motor Weight
19 kilograms

Recommended Minimum Wire Size
1.5 mm2

Protection Rating
IP65

Operating Temperature
0 to 40 degrees Celsius

Operating Altitude
Up to 1000 meters

Storage Temperature
-20 to 80 degrees Celsius

Frequently Asked Questions

Common Misspellings

Internal Product Review

The MHD093B-035-NP1-AN earns strong feedback for smooth and stable performance. Users mention its easy integration and predictable response in various setups. It continues to function reliably over long periods. Its steady behavior under demanding workloads makes it appealing for installations requiring consistent output and low maintenance over time.
