R911287180 (MHD115B-024-NP0-BN)
MHD Synchronous Motors
Technical Specifications
Function
Servo Motor
Housing
Natural Convection and Liquid Cooling
Continuous Torque at Standstill (60K overtemperature)
50 Nm
Continuous Current at Standstill (60K overtemperature)
32.3 A
Rated Speed (60K overtemperature)
2000 RPM
Rated Torque (60K overtemperature)
17.9 Nm
Rated Current (60K overtemperature)
8.2 A
Continuous Torque at Standstill (100K overtemperature)
57 Nm
Continuous Current at Standstill (100K overtemperature)
37.9 A
Rated Speed (100K overtemperature)
2000 RPM
Rated Torque (100K overtemperature)
32.3 Nm
Rated Current (100K overtemperature)
15.2 A
Continuous Torque at Standstill (Liquid Cooling)
95 Nm
Continuous Current at Standstill (Liquid Cooling)
61.4 A
Rated Speed (Liquid Cooling)
2000 RPM
Rated Torque (Liquid Cooling)
80.3 Nm
Rated Current (Liquid Cooling)
36.7 A
Characteristic Motor Speed
4000 RPM
Maximum Motor Speed
4000 RPM
Holding Brake
No
Power Connector Location
Side B
Main Shaft Features
Key and Seal
Protection Level
IP65
Insulation Class
F
Housing Color
Matte Black
Weight
40 Kg
Transportation Position
Horizontal
Impact Protection
Yes
Shaft Protective Sleeve
Yes
Frequently Asked Questions
Why is a keyed shaft design beneficial for industrial automation setups?
The keyed shaft ensures secure coupling between the motor and driven component. The design prevents slippage during torque transfer and enhances positional accuracy in precision drives.
How does removing the holding brake influence servo system response time?
The absence of a holding brake reduces rotor inertia. The faster acceleration and deceleration response improve cycle efficiency in dynamic positioning systems.
What are the integration advantages of the Bosch Rexroth Indramat MHD115B-024-NP0-BN in multi-axis systems?
The motor’s standardized mounting and connector interfaces enable plug-and-play integration. The consistent feedback and current profile simplify synchronization across multiple servo axes.
How does digital servo feedback enhance motion precision compared to analog types?
The digital encoder transmits high-resolution positional data with minimal noise interference. The consistent signal integrity enhances motion smoothness and repeatability during control operations.
What factors make this servo motor suitable for robotic and packaging systems?
The compact frame and high torque density allow installation in tight spaces. The efficient thermal control ensures reliable operation during continuous motion cycles.
Common Misspellings
MHD115B024NP0BN
MHD115B 024 NP0 BN
mhd115b-024-np0-bn
Internal Product Review
The Bosch Rexroth Indramat MHD115B-024-NP0-BN servo motor uses liquid cooling for consistent 50 Nm torque at standstill and digital servo feedback (HSF) for precise control. Its keyed shaft and sealed housing suit continuous motion applications in packaging automation and high duty metal forming machinery where stable thermal balance is essential.
