R911287309 (MHD093B-035-PG1-BA)

MHD Synchronous Motors

In Stock, Ships Today

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone

Part Number

+Add a message

Message

Request a Replacement

Request a Repair

Quote Both

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone:
1-888-551-3082

Email:
[email protected]

The Bosch Rexroth synchronous motor, MPN R911287309 (MHD093B-035-PG1-BA), is designed for use in precision automation systems. It features a plain shaft with shaft seal, flange dimensions of 140 mm or 150 mm, and a centering diameter of 130 mm. The motor weighs 19 kg and uses grease-lubricated bearings capable of supporting high radial loads. It operates with a natural convection cooling system and a class F insulation system according to DIN VDE 0530 Part 1. The integrated multiturn absolute encoder provides digital servo feedback for up to 4096 revolutions. Holding brake torque is 22.0 Nm, with 17.5 Nm continuous torque at standstill. The power connection is an output connector oriented to side B. Maximum speed is 4,500 min⁻¹, with all dimensions and tolerances in accordance with DIN 42948.

Technical Specifications

Holding Brake
22Nm

Use
Handling and automation systems

Design
Brushless, grease-lubricated bearings

Flange Specification
DIN 42948

Installation
Any desired position

Encoder
Integrated multiturn absolute encoder

Insulation
Class F, DIN VDE 0530 Part 1

Weight
19kg

Bearing
Designed for high radial loads

Modification
Not permitted

Installation, operation, servicing
As per documented specifications

Operation
As a main drive motor

Additional Components
Actuators, sensors

Tampering
May lead to damage

Temperature time constant
60 minutes (natural convection cooling)

Flange Size
140mm, 150mm

Centering Diameter
130mm

Shaft
Plain, end-sided centering hole with DS thread

Power Connector
Output direction towards B side

Winding Inductivity
10.7mH

Maximum Speed
4,500min-1

Transportation
Freight carriers

Frequently Asked Questions

Common Misspellings

Internal Product Review

The MHD093B-035-PG1-BA earns positive remarks for dependable performance and smooth functioning. Users highlight its straightforward integration and consistent behavior. It handles extended workloads without issues. Many value its steady output in demanding environments, making it an appealing option for installations that prioritize reliability and operational continuity over time.
