R911287467 (MHD093C-058-NG0-AA)

Name: R911287467 (MHD093C-058-NG0-AA)
Brand: Indramat Motors
SKU: MHD093C-058-NG0-AA
Price: 416.00 USD
Availability: InStock
Rating: 4.9 (11 reviews)

MHD Synchronous Motors

Rated 4.9 stars (11 total reviews)

Front Right

In-Stock, Ships 1-2 Days

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone

Part Number

+Add a message

Message

Request a Replacement

Request a Repair

Quote Both

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Current response time:

4 Minutes 16 Seconds

Phone:
1-888-551-3082

Email:
sales@indramat-usa.com

The synchronous motor R911287467 (MHD093C-058-NG0-AA) from the MHD series is engineered by Bosch Rexroth Indramat for industrial automation applications. This brushless servo motor has grease-lubricated bearings and a housing rated for water-tightness and resistance to harsh conditions. It features a motor size of 093, length C, a winding code of 058, and a digital servo feedback (HSF) encoder providing relative position detection. The plain shaft includes a sealing ring and does not have a holding brake. The housing supports natural convection cooling, with a centering diameter of 130 mm, a flange size of 140/150 mm, and connects electrically via an output connector on side A. Continuous torque at standstill is 23.0 Nm.

Technical Specifications

Motor Size
093

Motor Length
C

Windings Code
058

Motor Encoder
Digital Servo Feedback

Driven Shaft
Plain with Shaft Sealing Ring

Housing Design
Natural Convection and Surface Cooling

Brushless Design
Yes

Grease-Lubricated Bearings
Yes

Maintenance
Maintenance-free

Resistant Coating
Yes

Water-tight Seal
Yes

High-Performance Output
Yes

Suitable Environments
Adverse Conditions

Frequently Asked Questions

Does the MHD093C-058-NG0-AA include a holding brake?

No, the MHD093C-058-NG0-AA does not include a holding brake.

What cooling type is used in MHD093C-058-NG0-AA?

The MHD093C-058-NG0-AA uses natural convection cooling.

What encoder type does MHD093C-058-NG0-AA use?

The MHD093C-058-NG0-AA is fitted with a digital servo feedback HSF encoder.

What position detection is supported by MHD093C-058-NG0-AA?

The MHD093C-058-NG0-AA provides relative position detection.

What shaft seal option does MHD093C-058-NG0-AA feature?

The MHD093C-058-NG0-AA is supplied with a shaft seal.
