R911287551 (MHD115B-024-PP0-BA)

Name: R911287551 (MHD115B-024-PP0-BA)
Brand: Indramat Motors
SKU: MHD115B-024-PP0-BA
Price: 824.00 USD
Availability: InStock
Rating: 4.5 (14 reviews)

MHD Synchronous Motors

Rated 4.5 stars (14 total reviews)

Front Left

In-Stock, Ships 1-2 Days

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone

Part Number

+Add a message

Message

Request a Replacement

Request a Repair

Quote Both

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Current response time:

3 Minutes 16 Seconds

Phone:
1-888-551-3082

Email:
sales@indramat-usa.com

The R911287551 (MHD115B-024-PP0-BA) is a servo motor from the MHD series by Bosch Rexroth, designed for industrial automation applications. It features a robust, brushless, and grease-lubricated construction with a permanent magnet, enabling reliable operation. The motor has a 115 mm frame size, a 192 mm flange, and a 180 mm centering diameter. It is equipped with a keyed shaft, shaft seal, and an output connector oriented to side B. The digital servo feedback system includes a multi-turn absolute encoder for precise position control (greater than 4096 revolutions). Rated continuous torque at standstill is 50.0 Nm. The design supports natural convection cooling and conforms to IP65 for protection against harsh environments. This variant does not include a holding brake.

Technical Specifications

Industries Served
Automation, paper, packaging

Motor Type
Permanent-Magnet

Lubrication
Grease-lubricated design

Design Type
Brushless

Operational Conditions
Extreme work conditions

Protection Class
IP65

Heat Dissipation Type
Outside wall

Temperature Monitoring
Yes

Torque to Inertial Mass Ratio
High

Motor Frame Size
115 mm

Flange Size
192 mm

Centering Diameter
180 mm

Continuous Torque at Standstill (Natural Convection)
50 Nm

Motor Output Data Code
024

Motor Feedback System
Multi-turn absolute encoder

Shaft Design
With a keyway

Holding Brake
No

Output Connector Direction
Side B

Housing Type
Type A, suitable for natural convection

Shipping
Global

Frequently Asked Questions

Does the MHD115B-024-PP0-BA motor have a holding brake?

No, the Bosch Rexroth Indramat MHD115B-024-PP0-BA operates without a brake.

What is the shaft design of the MHD115B-024-PP0-BA?

The MHD115B-024-PP0-BA features a keyed shaft.

What encoder is used in the MHD115B-024-PP0-BA motor?

The Bosch Rexroth Indramat MHD115B-024-PP0-BA uses digital servo feedback with encoder.

What cooling method does the MHD115B-024-PP0-BA apply?

The MHD115B-024-PP0-BA operates with natural convection cooling.

What is the torque of the MHD115B-024-PP0-BA at standstill?

The Bosch Rexroth Indramat MHD115B-024-PP0-BA delivers 50.0 Nm torque.

Common Misspellings

MHD 115B 024 PP0 BA

MHD 115B-024-PP0-BA

MHD-115B-024-PP0-BA

MHD115B-O24-PPO-BA

MHD115B024PP0BA

MHDII5B-024-PP0-BA

MHD115B 024 PP0 BA

mhd115b-024-pp0-ba

Internal Product Review

The MHD115B-024-PP0-BA is often recognized for its balance between functionality and ease of use. Operators highlight its ability to integrate smoothly into different setups. Its consistent operation provides reassurance during demanding tasks. Reviews frequently mention that it supports efficient processes, proving to be a dependable part of various operational systems.
