R911288813 (MHD093B-058-NP1-AA)

Name: R911288813 (MHD093B-058-NP1-AA)
Brand: Indramat Motors
SKU: MHD093B-058-NP1-AA
Price: 199.00 USD
Availability: InStock

MHD Synchronous Motors

Front Left

In-Stock, Ships 3-5 Days

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone

Part Number

+Add a message

Message

Request a Replacement

Request a Repair

Quote Both

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone:
1-888-551-3082

Email:
sales@indramat-usa.com

The Indramat MPN R911288813 (MHD093B-058-NP1-AA) is a synchronous servo motor designed for precise motion control in industrial applications. It features a keyed shaft with shaft seal, a holding brake rated at 22 Nm and 24 VDC, and utilizes natural convection cooling along with an optional axial/radial blower for enhanced thermal management. The motor provides continuous torque at standstill of 17.5 Nm and operates within a speed range of 2500–4000 rpm, with an input voltage of 200–330 VAC. The housing is rated IP65 for dust and liquid resistance. Position detection is enabled by a digital servo feedback encoder (HSF) with ±0.5 arcmin precision. It has a centering diameter of 130 mm, flange size of 140/150 mm, and is classified as motor size 093, length B, with power output connection directed to side A.

Technical Specifications

Motor Type
Synchronous Motor

Blocking Brake Voltage
24 VDC

Brake Connection Time
25 ms

Brake Disconnection Time
50 ms

Cooling Method
Surface cooling with axial/radial blower

Blower Unit Voltage
AC 115 – 230 V

Blower Unit Operating Frequency
50/60 Hz

Input Power
AC 200 – 330 V

Continuous Torque
5.4 – 15 Nm

Operational Speed
2500 – 4000 rpm

Protection Level
IP65

Position Detection Method
Optical measuring with digital servo feedback

Motor Encoder Accuracy
±0.5 angular minutes

Shaft Type
Shaft with keyway

Startup Function
Quick startup

Environmental Temperature Range
0 to +40 degree Celsius.

Frequently Asked Questions

How much holding brake torque does the MHD093B-058-NP1-AA motor provide?

The MHD093B-058-NP1-AA motor offers a holding brake torque of 22.0 Nm.

What cooling method is used in the MHD093B-058-NP1-AA motor?

The MHD093B-058-NP1-AA motor is cooled by natural convection.

What shaft design is included on the MHD093B-058-NP1-AA motor?

The MHD093B-058-NP1-AA motor has a keyed shaft.

Where is the power connector located on the MHD093B-058-NP1-AA motor?

The MHD093B-058-NP1-AA motor has its power connection on side A.

Which winding code applies to the MHD093B-058-NP1-AA motor?

The MHD093B-058-NP1-AA motor uses winding code 058.

Common Misspellings

MHD093B058NP1AA

MHD093B 058 NP1 AA

mhd093b-058-np1-aa

MHD93B-058-NP1-AA

Internal Product Review

The MHD093B-058-NP1-AA is favored for its smooth functioning and straightforward setup. Users often mention its stable performance over prolonged use. It integrates well across various applications, providing consistent results without frequent adjustments. Many consider it a practical and dependable choice for regular operations.
