R911288882 (MHD112B-048-PG1-AN)

Name: R911288882 (MHD112B-048-PG1-AN)
Brand: Indramat Motors
SKU: MHD112B-048-PG1-AN
Price: 677.00 USD
Availability: InStock
Rating: 4.9 (13 reviews)

MHD Synchronous Motors

Rated 4.9 stars (13 total reviews)

Front Right

In-Stock, Ships 3-5 Days

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone

Part Number

+Add a message

Message

Request a Replacement

Request a Repair

Quote Both

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Current response time:

6 Minutes 23 Seconds

Phone:
1-888-551-3082

Email:
sales@indramat-usa.com

The Bosch Rexroth MPN R911288882 (MHD112B-048-PG1-AN) is a synchronous servo motor from the MHD series, featuring a winding code 048. This motor delivers a continuous torque at standstill of 28.0 Nm and a maximum torque of 102.0 Nm, with a peak current of 160.0 A. The speed range includes a nominal speed of 3500 min⁻¹ and a maximum speed of 4500 min⁻¹, with a frequency rating of 187 Hz. The torque constant is 0.88 Nm/A at 20°C. Constructed with a flange size of 192 mm and a centering diameter of 130 mm, the motor weighs 34.0 kg and includes liquid cooling and a plain shaft with shaft seal. Additional features include absolute position detection (>4096 revolutions) via digital servo feedback with an integrated encoder, an IP65 protection rating, insulation class F per DIN VDE 0530 Part 1, and a holding brake providing 22.0 Nm torque. The power connection is directed to side A with an output connector.

Technical Specifications

Product Category
MHD Synchronous Servo Motor

Characteristic Motor Speed
3500min-1

Peak Current
160.0A

Torque Constant at 20C
0.88Nm/A

Pole Pairs
4

Rated Speed
2800min-1

Rated Frequency
187Hz

Theoretical Maximum Torque
102.0Nm

Maximum Speed
4500min-1

Motor Mass
34.0kg

Ambient Temperature Range
0 to 40 Celsius

Insulation Class
F

Degree of Protection
IP65

Varnish Color
Black

Shipping Availability
Global

Product Subcategory
Servo motor numerical 048

Frequently Asked Questions

Does the MHD112B-048-PG1-AN motor include a holding brake?

Yes, the MHD112B-048-PG1-AN motor includes a holding brake.

What is the holding brake torque of the MHD112B-048-PG1-AN?

The MHD112B-048-PG1-AN motor has 22.0 Nm holding brake torque.

What shaft type is used in the MHD112B-048-PG1-AN motor?

The MHD112B-048-PG1-AN motor uses a plain shaft.

What is the continuous torque at standstill of the MHD112B-048-PG1-AN?

The MHD112B-048-PG1-AN motor provides 28.0 Nm torque at standstill.

Which cooling method is applied in the MHD112B-048-PG1-AN motor?

The MHD112B-048-PG1-AN uses liquid cooling.

Common Misspellings

MHD 112B 048 PG1 AN

MHD 112B-048-PG1-AN

MHD-112B-048-PG1-AN

MHD112B-O48-PG1-AN

MHD112B048PG1AN

MHDII2B-048-PGI-AN

MHD112B 048 PG1 AN

mhd112b-048-pg1-an

Internal Product Review

The MHD112B-048-PG1-AN is seen as a trustworthy solution for ongoing needs. Customers highlight its reliable functionality and smooth performance. Operators value the assurance it provides during daily operations. This model has a reputation for consistent results, making it a practical and dependable choice for professionals who require long-lasting, efficient performance every day.
