R911289796 (MHD093C-058-NP1-LA)

MHD Synchronous Motors

In Stock, Ships 2-3 Days

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone

Part Number

+Add a message

Message

Request a Replacement

Request a Repair

Quote Both

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Current response time:

6 Minutes 39 Seconds

Phone:
1-888-551-3082

Email:
[email protected]

The R911289796 (MHD093C-058-NP1-LA) is a Rexroth Indramat synchronous servo motor engineered for industrial automation. It features a keyed shaft with seal, housing for natural convection cooling, and digital servo feedback (HSF) for relative position detection. The unit delivers a continuous standstill torque of 23.0 Nm and includes an electrically-releasable holding brake rated at 22.0 Nm torque with 0.71 A current. The motor supports a rated input current of 7.9 A for up to 2.0 kW power at 2000 RPM, with maximum output speed reaching 6000 RPM and max input up to 127.4 A. The centering diameter is 130 mm, flange size 140/150 mm, with connector for both power and feedback interfaces.

Technical Specifications

Product Type
Industrial Synchronous Motor

Operation
Brushless

Use
Industrial Production and Processing Systems

Efficiency
95 percent for More than 5 Years

Rated Input Current
7.9 Amperes

Normalized Speed
2000 Revolutions per Minute

Power Output at Normalized Speed
2.0 Kilowatts

Peak Current
127.4 Amperes

Peak Speed
6000 Revolutions per Minute

Brake Type
Electrically Releasing Holding Brake

Brake Rated Current
0.71 Amperes

Brake Holding Torque
22.0-Newton Meters

Power and Motor Feedback Cable
Via Rotatable Connector

Cooling
Natural Convection and Optional External Blowe

Frequently Asked Questions

Common Misspellings

Internal Product Review

The MHD093C-058-NP1-LA servo motor by Bosch Rexroth features a keyed shaft, 22.0 Nm holding brake torque, and natural convection cooling. It offers 23.0 Nm continuous torque at standstill with digital servo feedback for relative position detection. This motor is commonly used in robotics, packaging, and CNC machinery applications.
