R911290837 (MHD112B-048-NP1-AN)

MHD Synchronous Motors

In Stock, Ships Today

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone

Part Number

+Add a message

Message

Request a Replacement

Request a Repair

Quote Both

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Current response time:

3 Minutes 55 Seconds

Phone:
1-888-551-3082

Email:
[email protected]

The R911290837 (MHD112B-048-NP1-AN) is a MHD series servo motor featuring digital servo feedback (HSF) and a 22 Nm holding brake operating at 24 V DC, with 25 ms connection and 50 ms disconnection times. The motor delivers a rated speed of 2800 RPM and a maximum speed of 4500 RPM, supporting a maximum current of 160 A and maximum torque of 102 Nm, with a continuous standstill torque of 28 Nm. It utilizes a keyed shaft with a shaft seal, 192 mm flange with a 130 mm centering diameter, and is equipped with a surface-cooled housing rated to IP65. Total mass is 34 kg, and installation requires four 14 mm flange holes. Handling should be performed by qualified personnel.

Technical Specifications

Holding Brake
22 Nm

Feedback Type
Digital servo feedback

Shaft Features
With key and sealing ring

Housing
Suited to surface cooling or natural convection

Power Connection Location
Side A of the motor housing

Rated Speed
2800 RPM

Maximum Speed
4500 RPM

Peak Current
160 Amps

Maximum Torque
102 Nm

Brake Voltage
24 Volts DC

Brake Current Consumption
0.71 Amps

Brake Connection Time
25 milliseconds

Brake Disconnection Time
50 milliseconds

Brake Weight
1.1 kilograms

Motor Weight
34 kilograms

Flange Size
192 millimeters

Centering Diameter
130 millimeters

Shaft Diameter
32 millimeters

Motor Length
375 millimeters

Mounting
Via four 14-millimeters holes on the motor flange

Housing Protection Category
IP65

Housing Surface
Painted matter black
