R911290859 (MHD093B-058-NP1-BA)

Name: R911290859 (MHD093B-058-NP1-BA)
Brand: Indramat Motors
SKU: MHD093B-058-NP1-BA
Price: 510.00 USD
Availability: InStock

MHD Synchronous Motors

Front Left

In-Stock, Ships 3-5 Days

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone

Part Number

+Add a message

Message

Request a Replacement

Request a Repair

Quote Both

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone:
1-888-551-3082

Email:
sales@indramat-usa.com

The Bosch R911290859 (MHD093B-058-NP1-BA) is an MHD093B series synchronous servo motor designed for high-torque, high-performance automation tasks. This model features a keyed shaft, shaft seal, and natural convection cooling. The motor supports a continuous standstill torque of 17.5 Nm, with holding brake torque rated at 22.0 Nm provided by a 24 VDC clamping brake. It offers digital servo feedback (HSF) for relative position detection and operates within a temperature range of 0 to 40°C. The motor casing meets IP65 protection standards and uses F-class insulation. Mechanical dimensions include a centering diameter of 130 mm, flange size of 140/150 mm, motor length B, and an overall mass of 19 kg. The power connection is made to side B via output connector. Winding code is 058.

Technical Specifications

Type
Synchronous Motor

Protection Category
IP65

Clamping Brake Voltage
24 VDC

Clamping Torque
22 Nm

Clamping Rated Current
0.71 A

Continuous Current
4.9 - 13.6 A

Continuous Torque
5.4 - 15 Nm

Performance at Natural Convection
1.7 - 4.1 kW

Performance at Natural Cooling
7.6 kW

Thermal Time Constant
30 - 60 min

Pole Pairs
4

Voltage Constant
79 V/1000 rpm

Torque Constant
0.87 Nm/A

Insulation Class
F

Permissible Temperature Range
0 to +40 degree Celsius

Weight
19 kg

Frequently Asked Questions

Where is the power connector positioned on the MHD093B-058-NP1-BA motor?

The MHD093B-058-NP1-BA motor has the connector on side B.

What shaft design is found on the MHD093B-058-NP1-BA motor?

The MHD093B-058-NP1-BA motor has a keyed shaft.

Which cooling method applies to the MHD093B-058-NP1-BA motor?

The MHD093B-058-NP1-BA motor uses natural convection.

What is the holding brake torque of the MHD093B-058-NP1-BA motor?

The MHD093B-058-NP1-BA motor provides 22.0 Nm of holding brake torque.

What winding code is assigned to the MHD093B-058-NP1-BA motor?

The MHD093B-058-NP1-BA motor uses winding code 058.

Common Misspellings

MHD093B058NP1BA

MHD093B 058 NP1 BA

mhd093b-058-np1-ba

MHD93B-058-NP1-BA

Internal Product Review

The MHD093B-058-NP1-BA is recognized for dependable performance in regular setups. Users appreciate how smoothly it operates and integrates. It functions well in extended use without disruptions. Its reputation for stability and ease of use makes it a suitable option for a variety of operational needs.
