R911291753 (MHD093B-035-PG1-LA)

MHD Synchronous Motors

In Stock, Ships Today

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone

Part Number

+Add a message

Message

Request a Replacement

Request a Repair

Quote Both

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Current response time:

4 Minutes 17 Seconds

Phone:
1-888-551-3082

Email:
[email protected]

The Bosch Rexroth R911291753 (MHD093B-035-PG1-LA) synchronous motor is designed to be handled, transported, and stored in a horizontal position without any load. Its installation, maintenance, and operation should only be carried out by technically trained professionals in a clean, dry environment. The device arrives with a protective plastic sleeve on the shaft which should be removed just prior to installation. The flange is secured with 4 x M10 screws with a minimum strength of 8.8 and 51Nm tightening torque. During operation, plug connectors must be securely tightened and should only be connected or disconnected when dry and de-energized, in accordance with the machine manufacturer's system circuit diagram. Perfect for environments up to 1,000m above sea level, factors such as ambient operating temperature and altitude should be considered. Furthermore, the included encoder must be correctly positioned, and the 66Nm torque, B length code motor's power connector flange socket can be rotated by 270 degrees. Before operation, thoroughly check electrical connections and alignment. Warranty extends to one year.

Technical Specifications

Orientation
Horizontal

Load during transportation
Not permissible

Lifting mechanism
Cranes with sling belt

Protective sleeve
Plastic, removed before mounting

Installation/Maintenance/Operation
carried out by skilled technical personnel

Environmental requirement
clean and dry

Mounting screws
4 x M10

Tightening Torque for mounting
51Nm

Minimum strength for mounting screws
8.8

Plug connectors
Must be tightly secured during operation

Maximum setup height
1000m over sea level

Transport availability
Global

Encoder position
Correct position on thread of connection housing

Torque
Maximum of 66Nm

Length code
B

Power connector socket
Flange, rotatable by 270 degrees
