R911292229 (MHD112C-035-PG0-BN)

Name: R911292229 (MHD112C-035-PG0-BN)
Brand: Indramat Motors
SKU: MHD112C-035-PG0-BN
Price: 555.00 USD
Availability: InStock
Rating: 4.6 (6 reviews)

MHD Synchronous Motors

Rated 4.6 stars (6 total reviews)

Front Left

In-Stock, Ships 1-2 Days

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone

Part Number

+Add a message

Message

Request a Replacement

Request a Repair

Quote Both

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone:
1-888-551-3082

Email:
sales@indramat-usa.com

The R911292229 (MHD112C-035-PG0-BN) is a Bosch Rexroth MHD series servo motor designed with a frame size of 112 and length C. It utilizes winding code 035 and features a plain shaft with a sealing ring. The encoder is a multi-turn absolute type, providing digital servo feedback with position detection above 4096 revolutions. The motor supports continuous torque at standstill of 38.0 Nm and features liquid cooling. The centering diameter is 130 mm with a flange size of 192 mm. Power connection is achieved via an output connector on side B, and separate connectors are provided for power and encoder. A temperature sensor is integrated, but holding brake is not included.

View Datasheet

Technical Specifications

Holding Brake
Not available

Connection Type
Separate plug connections

Power Connection Availability
Side B

Temperature Sensor Connection
Through power connector

Barcode Label
Present

Storage Condition
Dry, free from dust and vibration, horizontally

Storage Temperature Range
-20 to 80 degrees Celsius

Motor Frame Size
112

Motor Frame Length
C

Winding Code
035

Shaft Type
Plain with sealing ring

Servo Feedback
Digital, integrated multiturn absolute encoder

Cooling Method
Surface cooling

Global Shipping
Available

Frequently Asked Questions

Does MHD112C-035-PG0-BN include a holding brake?

The MHD112C-035-PG0-BN is supplied without a holding brake.

What type of cooling is on MHD112C-035-PG0-BN?

The MHD112C-035-PG0-BN uses liquid cooling.

What torque is available in MHD112C-035-PG0-BN?

The MHD112C-035-PG0-BN provides 38.0 Nm torque at standstill.

What encoder type is in MHD112C-035-PG0-BN?

The MHD112C-035-PG0-BN has digital servo feedback with integration.

What shaft type is in MHD112C-035-PG0-BN?

The MHD112C-035-PG0-BN uses a plain shaft with seal.
