R911293228 (MHD115B-024-PP0-LA)

Name: R911293228 (MHD115B-024-PP0-LA)
Brand: Indramat Motors
SKU: MHD115B-024-PP0-LA
Price: 851.00 USD
Availability: InStock

MHD Synchronous Motors

Front Left

In-Stock, Ships 1-2 Days

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone

Part Number

+Add a message

Message

Request a Replacement

Request a Repair

Quote Both

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Current response time:

5 Minutes 17 Seconds

Phone:
1-888-551-3082

Email:
sales@indramat-usa.com

The Bosch Rexroth R911293228 (MHD115B-024-PP0-LA) is a synchronous servo motor featuring natural convection housing cooling and a keyed shaft design with a shaft sealing ring. It does not include a holding brake and utilizes a multiturn digital servo feedback encoder for absolute position detection exceeding 4096 revolutions. Motor specifications include a continuous torque at standstill of 50.0 Nm, center diameter of 180 mm, and flange size of 192 mm. Winding inductivity is rated at 5.3 mH. The power connection is configured to the left using a power connector. Installation requires tightening cover screws to 1 Nm and 3 Nm torque values, and horizontal orientation must be observed during transport and storage. Mechanical installation must precede electrical connections, and de-energization is required before any maintenance.

Technical Specifications

Tightening Torques
1Nm and 3Nm

Protection Rating
IP 67

Housing Resistance
Coloring, weather, chalking

Optional Blower
Yes, ordered separately

Shaft Type
Keyway shaft

Shaft Sealing Ring
Rubbing seal

Length Code
C

Winding Inductivity
5.3mH

Orientation During Transport/Storage
Horizontal

Flange Holder Check
Required before mounting

Screws Tensile Strength
8.8

Mechanical Mounting
Required before electrical connection

De-energized During Maintenance
Yes

Encoder Connector Placement
On connection housing thread

Packaging
Rugged.

Frequently Asked Questions

Is the shaft on the MHD115B-024-PP0-LA keyed?

Yes, the MHD115B-024-PP0-LA features a shaft with a keyway that allows balancing with a key when coupling to provide optimal load distribution for efficient transmission of torque.

Does the MHD115B-024-PP0-LA support high-speed applications?

Yes, the MHD115B-024-PP0-LA offers a flexible speed range that allows high-speed operation while maintaining stability in torque delivery.

Can the MHD115B-024-PP0-LA be used in environments where ambient conditions fluctuate?

Yes, the MHD115B-024-PP0-LA has a wide temperature tolerance that allows it to remain stable when ambient conditions fluctuate. It can support temperatures of between o to +45 °C without derating in performance.

What frame type does the MHD115B-024-PP0-LA feature?

The MHD115B-024-PP0-LA features a B-type frame, indicating a compact construction that still maintains high power density for reliable performance.

Does the MHD115B-024-PP0-LA feature a brake for safe standstill?

No, the MHD115B-024-PP0-LA is not equipped with a holding brake. This design allows users to implement tailored braking solutions to suit their specific application needs.

Common Misspellings

MHD115B024PP0LA

MHD115B 024 PP0 LA

mhd115b-024-pp0-la

Internal Product Review

The MHD115B-024-PP0-LA offers reliable power output over a flexible speed range. Its robust stall torque enhances reliability in position-holding tasks. However, the mechanical output can be lower than ideal for very high-load applications.
