R911293229 (MHD115B-024-PP1-LA)

Name: R911293229 (MHD115B-024-PP1-LA)
Brand: Indramat Motors
SKU: MHD115B-024-PP1-LA
Price: 484.00 USD
Availability: InStock

MHD Synchronous Motors

Front Left

In-Stock, Ships 1-2 Days

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone

Part Number

+Add a message

Message

Request a Replacement

Request a Repair

Quote Both

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone:
1-888-551-3082

Email:
sales@indramat-usa.com

The R911293229 (MHD115B-024-PP1-LA) is a synchronous servo motor from Bosch Rexroth featuring a keyed shaft and shaft seal, with a motor size of 115 and length B. It is equipped with a digital servo feedback system and multiturn absolute encoder for position detection exceeding 4096 revolutions. The model provides a holding brake torque of 70 Nm and continuous standstill torque of 50 Nm. Electrical parameters include a winding inductance of 5.36 mH, resistance of 0.36 ohms, rated voltage of 24 V, and rated current of 1.29 A. It delivers 4.4 kW at 60 K with a maximum current draw of 8.2 A. The motor employs natural convection cooling with a thermal time constant of 100 minutes, and optional surface cooling reduces this to 45 minutes. The centering diameter is 180 mm with a flange size of 192 mm. The ingress protection is IP65, and the maximum ambient operating temperature is +40 °C. Power is supplied via a left-oriented power connector.

Technical Specifications

Weight
40 kg

Holding Brake Weight
3.8 kg

Holding Torque
70 Nm

Rated Current
1.29 A

Rated Voltage
24 V

Inductance of Windings
5.36 mH

Resistance
0.36 ohms

Inertia Moment
93.2 x 10-4 kgm2

Output
Keyed Shaft

Sealing
Top Ring

Constant Torque
75 Nm at 60/100-K

Surface Cooling Continuous Current
48.5 A

Shock Load Resistance
Shock-absorbing install

Thermal Time Constants
100 min (Natural), 45 min (Surface)

Theoretical Torque
160 Nm

Rated Torque
32.3 Nm

Rated Current (Natural Cooling)
15.2 A

Voltage Consumption (Natural Cooling)
321 V

Rated Power (60 K, Natural Cooling)
4.4 kW

Current Consumption (60 K, Natural Cooling)
8.2 A

Rotational Speed (Surface Cooling)
2000 rpm

Voltage Consumption (Surface Cooling)
337 A

Rated Frequency (Surface Cooling)
133 Hz

Max Ambient Temperature
+40 Celsius

Protection Rating
IP65

Encoder
Multiturn Absolute Encode

Frequently Asked Questions

How is the MHD115B-024-PP1-LA cooled?

The MHD115B-024-PP1-LA utilizes self-cooling using ambient air flow to dissipate heat during operation. This maintains thermal stability in continuous use, ensuring consistent performance.

How is the MHD115B-024-PP1-LA mounted?

The MHD115B-024-PP1-LA is a flange-mounted motor that comes with a flange interface for secure surface attachment, ensuring stable and secure installation in varied system layouts.

Does the MHD115B-024-PP1-LA offer simplified electrical integration?

Yes, the MHD115B-024-PP1-LA comes with a fitted power connector on its left side, allowing easy connection of power cables for quick and hassle-free setup.

What shaft type does the MHD115B-024-PP1-LA feature?

The MHD115B-024-PP1-LA features a shaft with keyway, enabling secure mechanical integration with other components.

Does the MHD115B-024-PP1-LA come with ingress protection?

Yes, the MHD115B-024-PP1-LA has an IP65-rated enclosure that maintains the integrity of its internal components by preventing dust and moisture from getting into the motor.

Common Misspellings

MHD115B024PP1LA

MHD115B 024 PP1 LA

mhd115b-024-pp1-la

Internal Product Review

The is well-suited for compact installations that require reliable power delivery. Its integration of braking and feedback capabilities keeps intial costs low. However, the permissable ambient range for operation may not hit environments.
