R911293524 (MHD112B-035-PP0-AN)

Name: R911293524 (MHD112B-035-PP0-AN)
Brand: Indramat Motors
SKU: MHD112B-035-PP0-AN
Price: 639.00 USD
Availability: InStock

MHD Synchronous Motors

Front Right

In-Stock, Ships 3-5 Days

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone

Part Number

+Add a message

Message

Request a Replacement

Request a Repair

Quote Both

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Current response time:

5 Minutes 57 Seconds

Phone:
1-888-551-3082

Email:
sales@indramat-usa.com

The Bosch MPN R911293524 (MHD112B-035-PP0-AN) is a servo motor from the MHD series, designed with a brushless, permanent magnet construction and digital servo feedback with an integrated encoder for absolute position detection over more than 4096 revolutions. This unit provides a continuous standstill torque of 28.0 Nm, supports a constant speed of 2500 RPM, and operates optimally within a temperature range of 0 to 40°C. Key features include a keyed shaft with shaft seal, motor length B, centering diameter of 130 mm, and flange size of 192 mm. The motor is equipped for liquid cooling, lacks a holding brake, and accepts power via an output connector oriented to side A. The overall weight is approximately 34 kg, and it conforms to the IP65 protection rating.

Technical Specifications

Motor Type
Brushless, Flange Mounted

Peak Torque Usable Range
Wide Speed Range

Motor Flange Size
112

Windings Code
035

Motor Flange Length
B

Encoder Type
Integrated Multiturn

Motor Shaft Key
According to DIN 6885-1

Sealing Ring
Included

Holding Brake
Not available

Optional Brakes
22 Nm, 32 Nm, 70 Nm

Motor Power Connector
On side A

Motor Cooling Options
Natural convection or surface

Rated Speed
2500 RPM

Working Temperature Range
0 to 40 degrees Celsius

Storage Temperature Range
-20 to 80 degrees Celsius

Protection Category
IP65

Weight
Approximately 34 kilograms.

Frequently Asked Questions

How does thermal management behave under repetitive load in closed machine environments?

The motor’s liquid cooling system actively stabilizes internal temperature during extended cyclic operation. It prevents thermal overload and reduces service interruptions in high-frequency applications.

What role does the MHD112B-035-PP0-AN’s feedback system play in axis synchronization accuracy?

Its integrated digital encoder delivers absolute position data over 4096+ revolutions. This ensures reliable multi-axis alignment in precision-controlled automation sequences.

Will mechanical coupling maintain stability in high-vibration or contaminated environments?

A keyed shaft combined with a shaft seal enhances torque transmission reliability. It also protects against ingress, increasing longevity under industrial operating conditions.

How does the power connector design influence electrical integration in pre-wired control cabinets?

The side A output connector simplifies layout in panel-constrained installations. It offers direct cable access and minimizes interference with adjacent devices.

What advantages does the MHD112B-035-PP0-AN offer in high-speed, brake-free cyclic motion systems?

Its brake-less design lowers rotor mass for faster acceleration and deceleration. This supports highly dynamic tasks with minimal mechanical drag.

Common Misspellings

MHD112B035PP0AN

MHD112B 035 PP0 AN

mhd112b-035-pp0-an

Internal Product Review

The MHD112B-035-PP0-AN from Bosch Rexroth Indramat is a servo motor featuring a centering diameter of 130 mm. It offers liquid cooling for thermal stability, a keyed shaft with shaft seal, digital servo feedback over 4096+ revolutions, and side A power connection. It is ideal for robotics, conveyors, and automated production lines.
