R911293586 (MHD090B-058-PP0-UP)

MHD Synchronous Motors

In Stock, Ships 2-3 Days

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone

Part Number

+Add a message

Message

Request a Replacement

Request a Repair

Quote Both

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone:
1-888-551-3082

Email:
[email protected]

The R911293586 (MHD090B-058-PP0-UP) is a Bosch Rexroth servo motor featuring a keyed shaft conforming to DIN 6885-1, an end-sided centering hole with DS thread, and a motor length of 264 mm (length B). It is designed with an aluminum-insulated flange socket, a centering diameter of 110 mm, and a flange size of 140 mm. The housing utilizes natural convection cooling with IP68 protection and is not intended for underwater operation. The unit includes a digital servo feedback system with an integrated absolute encoder (>4096 revolutions) and separate connectors for power and feedback, with a 270° turnable power connection. This motor has a continuous standstill torque of 12.0 Nm, is compatible with GTS, GTP, and GTM planetary gears, and operates at a frequency of 267 Hz. The shaft seal is included, and the design is suited for rugged loads when equipped with appropriate shock decoupling mechanisms. Lifetime lubrication minimizes maintenance requirements. There is no holding brake; winding code is 058.

Technical Specifications

Rated Frequency
267Hz

Encoder System
Integrated

Shaft Design
DIN 6885-1 specifications

Flange
Aluminum

Length
264mm

Efficiency
High

Maintenance
Low or no maintenance due to lifetime lubrication

Compatibility
GTS, GTP, and GTM planetary gearings

Construction
Completely closed and compact design

Elevation Support
0m to 1,000m above sea level

Installation
Possible in any orientation

Vendor Network
Worldwide availability.

Frequently Asked Questions

Common Misspellings

Internal Product Review

The MHD090B-058-PP0-UP offers steady results for long-term use. Operators value its dependable functioning and adaptability. Its design makes it suitable for continuous workloads. Many recognize its contribution to maintaining smooth processes. As a result, it is seen as a valuable solution for consistent performance in a range of systems.
