R911296513 (MHD112C-024-PP0-LN)

MHD Synchronous Motors

In Stock, Ships Today

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone

Part Number

+Add a message

Message

Request a Replacement

Request a Repair

Quote Both

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone:
1-888-551-3082

Email:
[email protected]

The R911296513 (MHD112C-024-PP0-LN) is a synchronous servo motor intended for dynamic motion control in industrial automation. It features liquid cooling, a housing with a DIN-compliant 192 mm flange, and a 130 mm centering diameter. The motor employs a digital servo feedback encoder system with absolute position detection beyond 4096 revolutions. It generates a continuous standstill torque of 38.0 Nm and operates at speeds up to 4000 rpm, with peak current rated at 120 A. The shaft is keyed with a shaft seal, and the power connection uses a left-oriented power connector. The design omits a holding brake, and winding code is 024.

Technical Specifications

Product Type
Synchronous Motor

Mounting
DIN compliant flange

Encoder System
High accuracy

Applications
High dynamic motion control

Usability
High speed start stop tasks

Design
Wide air gaps for mechanical stability

Torque
High availability across various speeds

Overload Capacity
High

Maximum Speed
4000 rpm

Energy Generation
High density due to quality permanent magnets

Peak Current
120 A

Extra Feature
Inbuilt data memory for fast start-up
