R911297890 (MHD115B-024-PG1-RA)

Name: R911297890 (MHD115B-024-PG1-RA)
Brand: Indramat Motors
SKU: MHD115B-024-PG1-RA
Price: 731.00 USD
Availability: InStock

MHD Synchronous Motors

Front Left

In-Stock, Ships 3-5 Days

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone

Part Number

+Add a message

Message

Request a Replacement

Request a Repair

Quote Both

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Current response time:

5 Minutes 23 Seconds

Phone:
1-888-551-3082

Email:
sales@indramat-usa.com

The R911297890 (MHD115B-024-PG1-RA) is a synchronous servo motor manufactured by Bosch Rexroth, equipped with digital servo feedback and an integrated multiturn absolute encoder supporting position detection exceeding 4,096 revolutions. This unit features a maximum peak current of 145A and a continuous standstill torque of 50.0 Nm. The motor is configured with a plain shaft including a shaft seal, natural convection housing cooling, a centering diameter of 180 mm, flange size of 192 mm, and is fitted with a holding brake rated at 70.0 Nm. Electrical connections are established on the right side via power connector, and the model supports compatibility with external fans or blowers through a three-core cable when required. It is intended for use in industrial applications, with parameter settings and handling performed only by trained personnel.

Technical Specifications

Peak current rating
145A

Encoder Type
Multiturn absolute encoder

Use restriction
Not for use underwater

Professional requirement
Qualified and trained personnel

Flange centering diameter
180mm

Encoder revolutions
Over 4096

Power Connector orientation
Left

Pole pairs
Four

Maintenance Requirement
Maintenance free

Design
B05 as per EN 60034-7

Additional Requirements
Can be fitted with a blower or a fan

Plug connections
Separate for feedback and power connectors

Frequently Asked Questions

What is the size of the MHD115B-024-PG1-RA motor?

The MHD115B-024-PG1-RA is a size 115 motor with a frame designation of B, indicating a moderately sized motor that is optimized for ease of integration without compromising power capabilities.

Does the MHD115B-024-PG1-RA come with a blocking brake?

Yes, the MHD115B-024-PG1-RA is equipped with a blocking brake to prevent accidental movement when the motor is stopped or paused. This enhances operational safety, safeguarding both users and nearby equipment.

Does the MHD115B-024-PG1-RA remain stable in fluctuating temperature conditions?

Yes, the MHD115B-024-PG1-RA features a broad temperature tolerance of 0 up to +45 °C, ensuring that performance remains stable even when temperatures fluctuate within this range.

Does the MHD115B-024-PG1-RA operate reliably in harsh environments?

Yes, the MHD115B-024-PG1-RA is optimized for demanding environments. It comes with IP65 protection that ensures that environmental stressors do not affect the performance of the motor.

What type of guarantee is available with the MHD115B-024-PG1-RA?

The MHD115B-024-PG1-RA comes with a one year service guarantee offered by Wake Industrial.

Common Misspellings

MHD115B024PG1RA

MHD115B 024 PG1 RA

mhd115b-024-pg1-ra

Internal Product Review

The MHD115B-024-PG1-RA offers excellent precision in positioning and speed control. Its integrated encoder delivers reliable motor feedback. However, users should check their setup for compatibility with the right-side power connection before purchase.
