R911298334 (MHD115B-024-PP0-BN)

Name: R911298334 (MHD115B-024-PP0-BN)
Brand: Indramat Motors
SKU: MHD115B-024-PP0-BN
Price: 916.00 USD
Availability: InStock

MHD Synchronous Motors

Front Left

In-Stock, Ships 1-2 Days

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone

Part Number

+Add a message

Message

Request a Replacement

Request a Repair

Quote Both

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone:
1-888-551-3082

Email:
sales@indramat-usa.com

The R911298334 (MHD115B-024-PP0-BN) is a Bosch Rexroth synchronous servo motor featuring a keyed shaft, shaft seal, and liquid cooling housing. Equipped with a digital servo feedback encoder supporting absolute position detection of over 4096 revolutions, the motor allows for integrated encoder memory. The unit provides a continuous standstill torque of 50.0 Nm and operates with a torque constant of 1.7 Nm/A. Electrical specifications include a voltage constant of 154 V/1000min⁻¹ at 20°C and a rated frequency of 100 Hz at 60K with natural convection cooling. The motor has a moment of inertia of 138 × 10⁻⁴ kg·m², weighs 55 kg, and features a flange size of 192 mm and centering diameter of 180 mm. The shaft power connection is directed to side B via an output connector. O-rings are made of Viton, supporting a coolant with a pH between 6 and 8. Power loss under less than ideal operating conditions is 1200 W. No holding brake is included.

Technical Specifications

Startup Process
Quick and easy

Certifications
cUL Recognized, CE Certified

Cooling Method
Liquid

Visibility of Type Label
Yes

Encoder System Accuracy
+/-0.5 angular minutes

Shaft Protection
Plastic protective sleeve

Installation and Service
By qualified trained personnel

Torque Constant
1.7Nm/A

Voltage Constant
154V/1000min-1 at 20°C

Application
Ideal for handling and automation systems

Design
Brushless

Bearings
With grease lubrication

Coolant
Liquid with pH value 6-8

Material of O-rings
Viton

Power Loss
Nominal 1200W

Weight
55kg without fan

Moment of Inertia
138 x 10-4 of the rotor

Installation Conditions
Free of oil and dust.

Frequently Asked Questions

Does the MHD115B-024-PP0-BN feature an integrated encoder?

Yes, the MHD115B-024-PP0-BN comes with a built-in multiturn encoder that optimizes positioning accuracy by providing real-time feedback on the position of the shaft.

What is the permissible operating range for the MHD115B-024-PP0-BN?

The MHD115B-024-PP0-BN operates optimally within a temperature range of 0 to +45 °C, enabling use in most industrial environments.

What type of environmental protection does the MHD115B-024-PP0-BN feature?

The MHD115B-024-PP0-BN features IP65 environmental protection, ensuring reliability in dusty and moist environments. This keeps the motor durable in diverse industrial conditions.

What is the power connection orientation for the MHD115B-024-PP0-BN?

The MHD115B-024-PP0-BN motor comes with a Side B power connection, making it compatible with systems with a similar power alignment.

What is the recommended altitude for installing the MHD115B-024-PP0-BN?

The MHD115B-024-PP0-BN is suited for an installation altitude of 0 to 1000 meters above sea level, supporting use in various industrial environments.

Common Misspellings

MHD115B024PP0BN

MHD115B 024 PP0 BN

mhd115b-024-pp0-bn

Internal Product Review

The MHD115B-024-PP0-BN is a reliable motor in systems that require balanced speed and torque delivery. It offers responsive performance with minimal lag. However, the liquid-cooled design can add to setup complexity.
