R911313740 (MHD093B-035-PP0-RN)

MHD Synchronous Motors

In Stock, Ships Today

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone

Part Number

+Add a message

Message

Request a Replacement

Request a Repair

Quote Both

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Current response time:

5 Minutes 34 Seconds

Phone:
1-888-551-3082

Email:
[email protected]

The R911313740 (MHD093B-035-PP0-RN) is a Rexroth Indramat industrial servo motor designed for applications requiring precise electrical-to-mechanical energy conversion. It features a DIN 42948-compatible flange, a keyed shaft with shaft seal, and liquid cooling for enhanced thermal management. The integrated digital servo feedback system provides absolute position detection over more than 4096 revolutions. This motor delivers a continuous standstill torque of 17.5 Nm. It has a centering diameter of 130 mm, flange size of 140/150 mm, overall length of 356 mm, width of 140 mm, and weighs approximately 14.5 kg. The embedded encoder enables digital signal output and on-board memory supports data retention during power-off. Acceptable operating ambient temperature is up to 45°C, with storage permissible up to 75°C. The power connection is oriented to the right, via a power connector. The motor does not include a holding brake.

Technical Specifications

Function
Convert Electrical Energy to Mechanical Energy

Operational Condition
Tested and Certified

Protection
Durable Housing

Flange Type
DIN 42948

Additional feature
Internal Encoder

Default Memory
Present for Startup

Maximum Installation Temperature
45 degrees Celsius

Storage Temperature
Up to 75 degrees Celsius

Length
356 millimeters

Thickness
140 millimeters

Weight
14.5 kilograms

Frequently Asked Questions

Common Misspellings

Internal Product Review

The MHD093B-035-PP0-RN is praised for dependable running and smooth behavior. Users mention its straightforward handling and reliable performance during continuous operation. It integrates well with different systems. Its consistent output builds trust over time, making it a dependable option for environments where stable functioning is essential for productivity.
