R911318948 (MHD112B-035-PP1-AN)

Name: R911318948 (MHD112B-035-PP1-AN)
Brand: Indramat Motors
SKU: MHD112B-035-PP1-AN
Price: 593.00 USD
Availability: InStock

MHD Synchronous Motors

Front Right

In-Stock, Ships 3-5 Days

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone

Part Number

+Add a message

Message

Request a Replacement

Request a Repair

Quote Both

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Current response time:

6 Minutes 9 Seconds

Phone:
1-888-551-3082

Email:
sales@indramat-usa.com

The Bosch Rexroth MPN R911318948 (MHD112B-035-PP1-AN) is a synchronous servo motor featuring a 24V holding brake rated at 0.71 A and delivering 22 Nm of holding torque. The device offers multiple mounting positions (IMB5, IMV1, IMV3) and features a keyed shaft with shaft seal, a centered diameter of 130 mm, flange size of 192 mm, and motor length type B. The power connection is via an A-side output connector. With an IP65 protection class, the motor supports ambient temperatures from 0 to +40°C and operation up to 1000 meters above sea level. Cooling options include natural and surface variants, with continuous torque at standstill up to 28 Nm and output power from 4.2 to 10.1 kW, depending on operating conditions. Integrated digital servo feedback with absolute position detection (>4096 revolutions) and class-F insulation are standard.

Technical Specifications

Motor Holding Brake Current
0.71 A

Clamping Torque
22 Nm

Mounting Positions
IMB5, IMV1, IMV3

Flange Design
192 mm

Centering Diameter
130 mm

Power Connector Position
Top

Environmental Protection
IP65

Cooling Mode
Surface and Natural

Output Shaft
Tapered

Constant Torque
13.5 - 33.1 Nm

Constant Power
8.9 - 21.7 A

Produced Power
4.2 - 10.1 kW

Operating Temperature Range
0 - 40 degree Celsius

Maximum Mounting Height
1000 MSL

Insulation Class
Class F

Protection Class
IP65

Control Method
HSF with integrated absolute encode

Frequently Asked Questions

Can this model integrate directly into standard motion assemblies without custom adapter plates?

Its 192 mm flange with 130 mm centering diameter matches industrial servo layouts. This allows straightforward mechanical integration into modular system frames.

How does the MHD112B-035-PP1-AN respond to loss-of-power scenarios in vertical load systems?

It integrates a 22.0 Nm holding brake for reliable static load retention. This maintains axis position securely during shutdown or emergency stops.

Does the shaft interface support precision engagement in sealed mechanical environments?

The keyed shaft with protective seal ensures tight torque transfer and ingress resistance. It performs reliably under mechanical stress and environmental exposure.

What positioning consistency can be expected in cyclic multi-axis control applications?

The digital feedback encoder provides absolute detection over 4096+ revolutions. It enables accurate closed-loop synchronization with minimal positional error.

How does the cooling method affect performance under sustained torque load?

The liquid cooling stabilizes thermal behavior during extended output at standstill. It prevents overheating and reduces performance drop-off in duty-intensive cycles.

Common Misspellings

MHD112B035PP1AN

MHD112B 035 PP1 AN

mhd112b-035-pp1-an

Internal Product Review

The Rexroth Indramat MHD112B-035-PP1-AN is a powerful servo motor equipped with a 22.0 Nm holding brake. It includes liquid cooling, a sealed keyed shaft, 28.0 Nm standstill torque, and a side-A power connector. The model's integrated encoder delivers high-precision absolute position detection across 4096+ revolutions effortlessly.
