MKD112A-058-KG1-BN
MKD Synchronous Motors
Technical Specifications
Shaft Design
Plain shaft
Shaft Seal
Yes
Holding Brake
With holding brake
Holding Brake Torque
22 Nm
Other Designs
None
Encoder Type
Resolver feedback w/ integrated encoder
Position Detection
Absolute (>4096 revs)
Continuous Torque at Standstill
15.0 Nm
Motor Length
A
Centering diameter
130 mm
Flange size
192 mm
Motor Size
112
Connection Direction
Side B
Connection Type
Output connector
Product type
Servo Motor
Winding Code
058
Frequently Asked Questions
What is the flange diameter for the MKD112A-058-KG1-BN?
The MKD112A-058-KG1-BN has a flange diameter of 130 mm for simplified mounting using standard mounting structures.
How is the MKD112A-058-KG1-BN integrated into existing setups?
The MKD112A-058-KG1-BN is integrated using flange mounting to ensure streamlined installation. This mounting method supports reliable performance with reduced vibrations for smooth rotations.
What is the peak temperature permitted for operating the MKD112A-058-KG1-BN?
The MKD112A-058-KG1-BN can be operated in ambient conditions of up to +45°C, providing adaptable performance in most industrial conditions.
Is the shaft on the MKD112A-058-KG1-BN keyed?
No, the shaft on the MKD112A-058-KG1-BN motor comes in a keyless design, ensuring a smooth surface for coupling seamlessly to other devices without requiring key balancing.
What type of service guarantee is available with the MKD112A-058-KG1-BN?
The MKD112A-058-KG1-BN comes with a 12-month warranty provided by Wake Industrial.
Common Misspellings
MKD112A058KG1BN
MKD112A 058 KG1 BN
mkd112a-058-kg1-bn
Internal Product Review
The MKD112A-058-KG1-BN is a sturdy motor with excellent environmental resilience. Its flexible speed and dynamic response capabilities enhance operational stability in demanding processes. However, installation can be time-consuming, especially for new users.
Shipping & Payment Options
Warranty
Repair
We offer a repair service for the MKD112A-058-KG1-BN.
Exchange
Want to sell your MKD112A-058-KG1-BN?
