MKD112A-058-KP0-BN
MKD Synchronous Motors
Technical Specifications
Shaft Design
Shaft with keyway
Shaft Seal
Yes
Holding Brake
Without holding brake
Other Designs
None
Encoder Type
Resolver feedback w/ integrated encoder
Position Detection
Absolute (>4096 revs)
Continuous Torque at Standstill
15.0 Nm
Motor Length
A
Flange size
192 mm
Motor Size
112
Connection Type
Output connector
Product type
Servo Motor
Winding Code
058
Cooling Method
Natural Convection
Rated Torque
28 Nm
Nominal Speed
3000 RPM
Weight
25 kg
Voltage
300V
Frequently Asked Questions
Is the MKD112A-058-KP0-BN equipped with a blower for cooling?
No, the MKD112A-058-KP0-BN does not come with a mounted blower. Its cooling system involves natural air cooling, dissipating heat naturally through the housing of the motor to maintain optimal internal temperatures.
What is the torque generated by the MKD112A-058-KP0-BN under rated conditions?
The MKD112A-058-KP0-BN generates 28.0 Nm of torque under rated conditions, balancing speed and torque performance for enhanced system reliability.
What type of brake is included with the MKD112A-058-KP0-BN?
The MKD112A-058-KP0-BN is a brake-free motor that does not feature an integrated brake.
Does the MKD112A-058-KP0-BN support vertical mounting orientation?
Yes, the MKD112A-058-KP0-BN supports flange mounting in either vertical or horizontal orientation to suit varied system and application needs.
What is the nominal speed delivered by the MKD112A-058-KP0-BN?
The MKD112A-058-KP0-BN delivers a nominal speed of 3000 rpm, enabling stable performance across various motion control tasks.
Common Misspellings
MKD112A058KP0BN
MKD112A 058 KP0 BN
mkd112a-058-kp0-bn
Internal Product Review
The MKD112A-058-KP0-BN is optimized for industrial use with a durable housing. It operates with minimal need for maintenance, making it a cost-effective option for most applications. However, the 25 kg weight may be a bit cumbersome for very compact spaces.
