MKD112B-024-KP0-AN
MKD Synchronous Motors
The MKD112B-024-KP0-AN is a servo motor from Bosch Rexroth Indramat's MKD Synchronous Motors series. It features resolver feedback w/ integrated encoder for absolute position detection over 4096 revs, delivers 28.0 Nm continuous torque at standstill and reaches up to 4500 RPM. With a 0.27 Nm/A torque constant, protection class IP65, a 192 mm flange, and a shaft with keyway and seal, it operates between 0 to 40°C and draws peaks of 105A.
Technical Specifications
Shaft Design
Shaft with keyway
Shaft Seal
Yes
Holding Brake
Without holding brake
Other Designs
None
Encoder Type
Resolver feedback w/ integrated encoder
Position Detection
Absolute (>4096 revs)
Continuous Torque at Standstill
28.0 Nm
Motor Length
B
Motor Size
112
Flange size
192 mm
Connection Type
Output connector
Product type
Servo Motor
Winding Code
024
Protection Class
IP65
Peak Current
105A
Ambient Temperature
0 to 40°C
Maximum Speed
4500 RPM
Torque Constant
0.27 Nm/A
Frequently Asked Questions
Why is torque delivery important for MKD112B-024-KP0-AN?
Providing 28.0 Nm standstill torque, the motor securely holds loads during idle or paused phases, ensuring stability and alignment for machinery that requires precise positioning between motion cycles.
How does speed capacity define MKD112B-024-KP0-AN?
With a peak speed of 4500 RPM, the motor supports rapid traverse movements, enabling shorter cycle times while maintaining controlled motion in automated systems that demand high-speed performance.
Why does torque constant matter in MKD112B-024-KP0-AN?
Rated at 0.27 Nm/A, the torque constant links current input to output torque accurately, allowing precise control of force applied and efficient energy usage in dynamic operations.
How does current demand affect MKD112B-024-KP0-AN?
Drawing up to 105 A, the motor’s peak current informs proper inverter sizing and cable specification, ensuring electrical compatibility and preventing overload during high-demand operation.
What role does IP rating serve in MKD112B-024-KP0-AN?
With IP65 protection, the motor resists dust ingress and water spray, enabling reliable operation in harsh industrial environments and reducing maintenance requirements over extended service life.
Common Misspellings
MKD 112B-024-KP0-AN
MKD-112B-024-KP0-AN
MKD112B-O24-KPO-AN
MKD112B024KP0AN
MKD112B 024 KP0 AN
mkd112b-024-kp0-an
Internal Product Review
This MKD112B-024-KP0-AN is one of the most rated and primal for ideal results. It emphasizes precision with resolver feedback and absolute detection. Its keyed shaft secures torque transfer. With 105 A peak current and 0.27 Nm/A torque constant, the motor balances responsiveness and strength.
