MKD112B-048-GP0-AN
MKD Synchronous Motors
The Bosch Rexroth Indramat MKD112B-048-GP0-AN from the MKD Synchronous Motors series is a Type synchronous motor optimized for high-performance servo applications. This product type Servo Motor delivers a continuous torque at standstill of 28.0 Nm and a rated torque of 24 Nm for dynamic load handling. With a rated power of 7.5 kW and a winding code 048, the motor is engineered to meet rigorous precision and power requirements. The compact motor size 112 frame and motor length B make it suitable for installations with strict space constraints.
Crafted for seamless integration, the MKD112B features a flange size 192 mm and a robust shaft design with keyway that ensures secure coupling to driven equipment. The inclusion of a shaft seal Yes protects internal components from contaminants, while the absence of a holding brake Without holding brake streamlines maintenance. Connectivity is simplified through a Connector Type Straight and an output connector Connection Type, ensuring reliable signal and power routing. Precision position feedback is provided by an Encoder Type Resolver feedback (RSF) with position detection Relative, enabling fine motion control.
Designed with durability and ease of use in mind, this servo motor supports standard configurations without the need for other designs None. The absence of a holding brake reduces mechanical complexity and minimizes downtime for routine servicing. As part of Bosch Rexroth Indramat’s MKD series, the MKD112B-048-GP0-AN combines robust construction and high-accuracy feedback to deliver consistent, efficient operation across diverse industrial environments.
Technical Specifications
Shaft Design
Shaft with keyway
Shaft Seal
Yes
Holding Brake
Without holding brake
Other Designs
None
Encoder Type
Resolver feedback (RSF)
Position Detection
Relative
Continuous Torque at Standstill
28.0 Nm
Motor Length
B
Motor Size
112
Flange size
192 mm
Connection Type
Output connector
Product type
Servo Motor
Winding Code
048
Connector Type
Straight
Rated Power
7.5 kW
Length
487 mm
Type
Synchronous Motor
Rated Torque
24 Nm
