MKD112C-024-GP0-RN

MKD Synchronous Motors

In Stock, Ships 2-3 Days

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone

Part Number

+Add a message

Message

Request a Replacement

Request a Repair

Quote Both

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone:
1-888-551-3082

Email:
[email protected]

The Bosch Rexroth Indramat MKD112C-024-GP0-RN is a servo motor in the MKD Synchronous Motors series and uses resolver feedback (RSF). The motor delivers 38.0 Nm continuous torque at standstill, runs up to 3000 RPM, and carries an IP65 protection class. It operates in 0 to 40 °C ambient temperature and features a shaft with keyway.

Technical Specifications

Shaft Design
Shaft with keyway

Shaft Seal
Yes

Holding Brake
Without holding brake

Other Designs
None

Encoder Type
Resolver feedback (RSF)

Position Detection
Relative

Continuous Torque at Standstill
38.0 Nm

Motor Length
C

Centering diameter
130 mm

Flange size
192 mm

Connection Direction
Right

Product type
Servo Motor

Winding Code
024

Protection Class
IP65

Speed
3000 RPM

Housing
Sealed

Insulation Class
F

Ambient Temperature
0 to 40 °C
