MKD112C-024-GP2-AN
MKD Synchronous Motors
The MKD112C-024-GP2-AN is a servo motor from Bosch Rexroth Indramat's MKD Synchronous Motors series, featuring a shaft with keyway and resolver feedback (RSF) for relative position detection. It delivers 38.0 Nm continuous torque at standstill at 3000 RPM, with 0.1 Ohm resistance and 5 mH inductance. Equipped with a holding brake and incremental encoder feedback, this size 112 motor with C length and 50 kg weight offers reliable performance.
Technical Specifications
Shaft Design
Shaft with keyway
Shaft Seal
Yes
Other Designs
None
Encoder Type
Resolver feedback (RSF)
Position Detection
Relative
Continuous Torque at Standstill
38.0 Nm
Motor Length
C
Motor Size
112
Connection Direction
Side A
Product type
Servo Motor
Winding Code
024
Holding Brake
Equipped
Feedback Type
Incremental Encoder
Rated Speed
3000 RPM
Resistance
0.1 Ohm
Inductance
5 mH
Weight
50 kg
Frequently Asked Questions
What is the nominal velocity for the MKD112C-024-GP2-AN?
The MKD112C-024-GP2-AN offers a nominal velocity of 3000 RPM, ensuring reliable operation with adjustable speeds for varied application needs.
Does the MKD112C-024-GP2-AN come with a holding brake?
Yes, the MKD112C-024-GP2-AN comes with a built-in brake that prevents motor movement when the system is turned off. This ensures operational safety.
Can the MKD112C-024-GP2-AN be installed in horizontally?
Yes, the flange mounting construction of the MKD112C-024-GP2-AN supports horizontal mounting as well as vertical, giving users ample flexibility when installing.
What type of shaft is the MKD112C-024-GP2-AN equipped with?
The MKD112C-024-GP2-AN is equipped with a shaft with a keyway that provides optimized mechanical integration for stable system operation.
Can the MKD112C-024-GP2-AN withstand fluctuations in ambient conditions?
Yes, the MKD112C-024-GP2-AN has a broad temperature tolerance that allows it to remain consistent when temperatures fluctuate within the permissible range of 0 to +45 °C.
Common Misspellings
MKD112C024GP2AN
MKD112C 024 GP2 AN
mkd112c-024-gp2-an
Internal Product Review
The MKD112C-024-GP2-AN is compact but efficient. Its construction supports simplified integration, but some setups might be too small for the 50 kg mass.
