MKD112C-024-GP2-BN
MKD Synchronous Motors
The Bosch Rexroth Indramat MKD112C-024-GP2-BN servo motor from the MKD Synchronous Motors series is a high-performance Servo Motor featuring a motor size of 112 and a compact motor length of C, with a robust shaft design incorporating a shaft with keyway and shaft seal. It delivers a continuous standstill torque of 38.0 Nm and a peak torque of 90.0 Nm at a peak current of 112.5 A, driven by a voltage constant of 24 V and a winding code of 024. Feedback is provided by a resolver feedback (RSF) encoder for relative position detection, while an integrated holding brake ensures safe stops. Designed with no additional designs and a side B connection direction, this IP65-rated motor weighs 35.2 kg for demanding industrial applications.
Technical Specifications
Shaft Design
Shaft with keyway
Shaft Seal
Yes
Other Designs
None
Encoder Type
Resolver feedback (RSF)
Position Detection
Relative
Continuous Torque at Standstill
38.0 Nm
Motor Length
C
Motor Size
112
Connection Direction
Side B
Product type
Servo Motor
Winding Code
024
Holding Brake
Equipped
Peak Current
112.5 A
Weight
35.2 kg
Voltage Constant
24 V
Protection Class
IP65
Peak Torque
90.0 Nm
Frequently Asked Questions
Can the MKD112C-024-GP2-BN sustain high-load conditions?
Yes, the MKD112C-024-GP2-BN comes with a peak torque capability of 90.0 Nm that enables it to handle high load conditions in dynamic tasks.
What frame size does the MKD112C-024-GP2-BN feature?
The MKD112C-024-GP2-BN comes with a size C frame that provides high power density optimized for high-load motion control processes.
Does the MKD112C-024-GP2-BN come with an integrated holding brake?
Yes, the MKD112C-024-GP2-BN is equipped to handle standstill efficiently with an integrated brake that maintains shaft position when the motor is not powered.
What operation specifications does the MKD112C-024-GP2-BN feature?
The MKD112C-024-GP2-BN requires moderate operating temperatures of 0 to 40 degrees Celsius to maintain thermal stability and prevent performance loss.
Can you use the MKD112C-024-GP2-BN in tough environments?
Yes, the MKD112C-024-GP2-BN comes in a sturdy build that is protected against environmental damage for longevity even in tough environments.
Common Misspellings
MKD112C024GP2BN
MKD112C 024 GP2 BN
mkd112c-024-gp2-bn
Internal Product Review
With its integrated feedback and brake features, the MKD112C-024-GP2-BN is easy to commission and set up. However, the shaft comes with a keyway which can make coupling complex in certain setups.
