MKD112C-024-KG0-LN
MKD Synchronous Motors
The MKD112C-024-KG0-LN is a servo motor by Bosch Rexroth Indramat in the MKD Synchronous Motors series. It offers 38.0 Nm continuous torque at standstill and 41 Nm max torque, uses resolver feedback w/ integrated encoder for absolute (>4096 revs) position detection, and features a plain shaft, IP65 rating, and flange type mounting on a 130 mm centering diameter. Weighing 11.5 kg with a cable box left connection, this size 112, C-length design excludes a holding brake.
Technical Specifications
Shaft Design
Plain shaft
Shaft Seal
Yes
Holding Brake
Without holding brake
Other Designs
None
Encoder Type
Resolver feedback w/ integrated encoder
Position Detection
Absolute (>4096 revs)
Continuous Torque at Standstill
38.0 Nm
Motor Length
C
Motor Size
112
Centering diameter
130 mm
Connection Direction
Left
Product type
Servo Motor
Winding Code
024
Max Torque
41 Nm
Mounting
Flange Type
Weight
11.5 kg
Protection Class
IP65
Connection
Cable Box
Frequently Asked Questions
What does the MKD112C-024-KG0-LN weigh?
The MKD112C-024-KG0-LN is a compact motor with a weight of 11.5 kg that makes it easy to handle and install.
Does the MKD112C-024-KG0-LN support high torque applications?
Yes, the MKD112C-024-KG0-LN comes with a rated peak torque of 41.0 Nm, enabling it to remain stable in operation even under high loads.
Can the MKD112C-024-KG0-LN operate in harsh environments?
Yes, the MKD112C-024-KG0-LN is well-suited for harsh settings due to a protective sealing that prevents dust and moisture ingress.
Does the MKD112C-024-KG0-LN feature an integrated brake?
No, the MKD112C-024-KG0-LN comes in a brake-free design that keeps system integration simple and space efficient.
What temperature tolerance does the MKD112C-024-KG0-LN provide?
The MKD112C-024-KG0-LN provides a temperature tolerance of 0 to +40 degrees Celsius, ensuring stability in most industrial conditions.
Common Misspellings
MKD112C024KG0LN
MKD112C 024 KG0 LN
mkd112c-024-kg0-ln
Internal Product Review
The MKD112C-024-KG0-LN is energy-efficient without compromising on power output. It is relatively easy to mount. However, it does not come with an inetgarted brake.
