MKD112C-024-KG2-AN

MKD Synchronous Motors

  In Stock, Ships 2-3 Days
Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping
Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

The Bosch Rexroth Indramat MKD112C-024-KG2-AN is a high-performance servo motor from the distinguished MKD Synchronous Motors series, designed to deliver precision motion control and robust power in demanding industrial settings. With a rated power of 23.4 kW and a continuous torque at standstill of 38.0 Nm, this motor provides both dynamic responsiveness and sustained force for applications such as robotics, automation, and machine tooling. Its compact design and advanced engineering make the MKD112C-024-KG2-AN an ideal choice where consistent performance and reliability are paramount.



This servo motor features a nominal speed of 6000 RPM and a maximum speed of 8000 RPM, ensuring rapid acceleration and precise speed regulation. It employs resolver feedback w/ integrated encoder technology coupled with absolute (>4096 revs) position detection, enabling high-resolution feedback and accurate positioning over multiple revolutions. The motor’s winding code is 024, reflecting optimized coil configurations for efficient power delivery and thermal management. As part of the MKD series, it maintains industry-grade tolerances, offering repeatable motion control and seamless integration with digital drives and CNC systems.



Built for durability and ease of installation, the MKD112C-024-KG2-AN features a plain shaft with a reliable shaft seal to protect internal components from contaminants. It is equipped with a holding brake for secure load retention during power loss or emergency stops. The flange mounting design (flange size: 192 mm) and side A connection direction streamline mechanical coupling and cabling in tight machine layouts. Weighing 45 kg, this motor balances rigidity with manageable mass, reducing vibration and enhancing operational stability. In industrial applications, the MKD112C-024-KG2-AN stands out for its exceptional efficiency, compatibility with standard mounting platforms, and long service life, delivering measurable improvements in productivity and machine uptime.

Technical Specifications

Shaft Design
Plain shaft

Shaft Seal
Yes

Other Designs
None

Encoder Type
Resolver feedback w/ integrated encoder

Position Detection
Absolute (>4096 revs)

Continuous Torque at Standstill
38.0 Nm

Motor Length
C

Flange size
192 mm

Connection Direction
Side A

Product type
Servo Motor

Winding Code
024

Nominal Speed
6000 RPM

Holding Brake
Equipped

Mounting
Flange

Rated Power
23.4 kW

Weight
45 kg

Max Speed
8000 RPM

Common Misspellings

Shipping & Payment Options
DHL-logo FexEd-logo UPS-logo freight-icon

AmEx-icon Mastercard-icon Visa-icon wire-transfer-icon
Warranty
1-year-warranty
Indramat USA 1 Year Warranty
Repair
We offer a repair service for the MKD112C-024-KG2-AN.
