MKD112C-024-KG3-RN
MKD Synchronous Motors
The Bosch Rexroth Indramat MKD112C-024-KG3-RN from the MKD Synchronous Motors series is a high-performance Servo Motor designed for precision motion control. With a compact motor size 112 frame and flange mounting, this unit delivers a robust continuous torque at standstill of 38.0 Nm while maintaining an overall degree of protection IP65 for harsh environments. The ambient temperature range of 0-40°C and natural convection cooling system ensure reliable operation without auxiliary fans. Engineered with a plain shaft design featuring a shaft seal, the MKD112C motor balances durability and ease of integration.
The drive includes a sophisticated resolver feedback w/ integrated encoder supporting absolute position detection for more than 4096 revolutions, enabling repeatable positioning in complex automation tasks. A built-in holding brake with a brake torque of 70 Nm secures loads instantaneously on power loss, while the rotor inertia of 0.014 kgm² provides fast dynamic response and minimal overshoot. The centering diameter of 130 mm and connection direction on the right facilitate straightforward mechanical alignment and cabling. Other designs are None, simplifying the selection process for standard applications.
Winding specifications are clearly defined by the winding code 024 and a motor length C, ensuring consistent thermal and electrical characteristics across units. The MKD112C-024-KG3-RN supports flexible installation into multi-axis systems thanks to its precise geometry and standardized interfaces. Whether used in packaging machines, pick-and-place robots, or precision assembly equipment, this motor provides the reliability and accuracy demanded by advanced industrial automation solutions.
Technical Specifications
Shaft Design
Plain shaft
Shaft Seal
Yes
Holding Brake
With holding brake
Holding Brake Torque
70 Nm
Other Designs
None
Encoder Type
Resolver feedback w/ integrated encoder
Position Detection
Absolute (>4096 revs)
Continuous Torque at Standstill
38.0 Nm
Motor Length
C
Centering diameter
130 mm
Motor Size
112
Connection Direction
Right
Product type
Servo Motor
Winding Code
024
Degree Of Protection
IP65
Mounting Type
Flange Mounting
Ambient Temperature Range
0-40°C
Cooling System
Natural Convection
Rotor Inertia
0.014 kgm²
