MKD112C-024-KP0-RN
MKD Synchronous Motors
The Bosch Rexroth Indramat MKD112C-024-KP0-RN from the MKD Synchronous Motors series is a high-precision servo motor engineered for demanding motion control applications. It delivers a continuous torque at standstill of 38.0 Nm and operates at a rated speed of 3000 RPM, with a maximum speed reaching 4000 RPM. Designed for three-phase 380-480 V power supplies, it features a moment of inertia of 0.033 kg·m² to balance dynamic response and torque density. The compact motor length C frame, paired with a centering diameter of 130 mm and a flange size of 192 mm, ensures straightforward integration into standardized drive systems.
Incorporating a resolver feedback with integrated encoder and absolute position detection capable of over 4096 revolutions, this motor enables precise, repeatable positioning without homing routines. The shaft with keyway design offers reliable torque transmission, while the optional shaft seal helps protect internal components in moderately contaminated environments. Mounting flexibility is enhanced by a standard mounting flange and a right-hand connection direction, simplifying cable routing in compact cabinets. With a winding code of 024 and no alternative designs or holding brake installed, the MKD112C-024-KP0-RN represents a streamlined solution for OEMs focusing on repeatability and minimal customization.
The MRD112C-024-KP0-RN’s robust construction and integrated absolute encoder make it ideal for high-duty-cycle automation where precise feedback is critical. Its balance of torque, speed range, and low inertia supports rapid acceleration and deceleration profiles without sacrificing control fidelity. By leveraging these MKD Series attributes, system designers can achieve optimized performance in packaging, robotics, and assembly applications that demand both reliability and accuracy.
Technical Specifications
Shaft Design
Shaft with keyway
Shaft Seal
Yes
Holding Brake
Without holding brake
Other Designs
None
Encoder Type
Resolver feedback w/ integrated encoder
Position Detection
Absolute (>4096 revs)
Continuous Torque at Standstill
38.0 Nm
Motor Length
C
Centering diameter
130 mm
Flange size
192 mm
Connection Direction
Right
Product type
Servo Motor
Winding Code
024
Rated Speed
3000 RPM
Moment Of Inertia
0.033 kg·m²
Power Supply
380-480 V
Maximum Speed
4000 RPM
Mounting Flange
Standard
Frequently Asked Questions
How does the 0.033 kg·m² inertia of MKD112C-024-KP0-RN affect servo loop tuning and acceleration in indexing/contouring tasks?
Its lower inertia eases acceleration yet demands careful gain scheduling to avoid overshoot with the motor’s 38 Nm stall capability. It supports crisp position settling for packaging and robotics when jerk limits are enforced.
For the three-phase supply on MKD112C-024-KP0-RN, which drive/cabling practices minimize common-mode noise and feedback interference?
The use of resolver-compatible drives and shielded motor/feedback cables with proper 360° shield terminations at the cabinet bulkhead maintain separation from mains.
How do the 192 mm flange and 130 mm centering diameter streamline mechanical retrofits?
These standardized interfaces simplify drop-in swaps on machinery designed around MKD112 geometry to preserve alignment and concentricity tolerances. It shortens fixture redesign while keeping shaft-height and coupling envelopes constant.
How do 38 Nm continuous torque and a 3000 RPM base speed map to application classes?
They align well with pick-and-place robotics to form-fill-seal axes and machine-tool feeds that need brisk indexing with steady torque. It is useful in industries such as robotics, printing and food lines among typical MKD112 deployments.
How does the right-hand connector orientation on MKD112C-024-KP0-RN influence cabinet layout and bend-radius planning?
It determines cable exit and strain-relief geometry that often permits tighter routing on right-hinged enclosures. It maintains manufacturer-specified minimum bend radii to protect resolver leads from induced noise and premature insulation fatigue.
Common Misspellings
MKD 112C-024-KP0-RN
MKD-112C-024-KP0-RN
MKD112C-O24-KPO-RN
MKD112C024KP0RN
MKD112C 024 KP0 RN
mkd112c-024-kp0-rn
Internal Product Review
The MKD112C-024-KP0-RN motor from Indramat generates 38 Nm stall torque and offers 3000 RPM of rated speed. It inertia value is 0.033 kg·m² for agile indexing and its multiturn absolute resolver feedback preserves repeatability without homing. This motor is powered from a three-phase 380 – 480 V source and it possess keyway shaft to fit into packaging, CNC machining and robotics.
