MKD112C-058-KG0-RN, Bosch Rexroth Indramat, MKD Synchronous Motors form a high-performance servo solution engineered for precision motion control in demanding industrial applications. This servo motor features a robust plain shaft arrangement paired with an optional shaft seal to guard internal components against contaminants, while the design intentionally omits a holding brake to maximize dynamic response. With a compact C motor length and a flange size of 192 mm, it balances power density and installation flexibility. The integrated encoder feedback system ensures closed-loop accuracy and repeatability across complex motion profiles.
Built around a Winding Code 058, the MKD112C-058-KG0-RN delivers a continuous torque at standstill of 38.0 Nm and a rated torque of 18.5 Nm, surging to a peak of 52 Nm for transient loads. The motor spins up to 3000 rpm on a rated current draw of 15.2 A, all while shedding heat through natural convection cooling without the need for auxiliary fans. Position detection is achieved via resolver feedback with integrated encoder offering absolute (>4096 revs) capability, and it meets precise centering requirements with a centering diameter of 130 mm. A right-hand connection direction simplifies cable routing in cabinet-mounted or direct-drive installations.
Seamless integration with Rexroth Indramat drive controllers ensures tight synchronization and deterministic response, while the sturdy construction and passive cooling strategy promote long-term reliability in continuous-duty environments. The absence of complex brake mechanisms reduces maintenance intervals and eliminates potential failure points. Ideal for packaging machines, pick-and-place systems, and CNC tools, the MKD112C-058-KG0-RN enhances throughput and accuracy where compact footprint and high dynamic performance are key.
Shaft Design
Plain shaft
Shaft Seal
Yes
Holding Brake
Without holding brake
Other Designs
None
Encoder Type
Resolver feedback w/ integrated encoder
Position Detection
Absolute (>4096 revs)
Continuous Torque at Standstill
38.0 Nm
Motor Length
C
Flange size
192 mm
Centering diameter
130 mm
Connection Direction
Right
Product type
Servo Motor
Winding Code
058
Rated Speed
3000 rpm
Rated Torque
18.5 Nm
Peak Torque
52 Nm
Cooling Method
Natural Convection
Rated Current
15.2A
