R911268916 (MKD112B-048-GG0-BN)

MKD Synchronous Motors

Rated 4.1 stars (12 total reviews)

In Stock, Ships 2-3 Days

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone:
1-888-551-3082

Email:
[email protected]

The Indramat MPN R911268916 (MKD112B-048-GG0-BN) is a MKD series digital AC synchronous servo motor with a size 112 frame and 192 mm flange. It features a plain shaft with sealing rings, lacks a holding brake, and is equipped with RSF resolver feedback for relative position detection. The unit uses a 048 winding code and operates with natural surface cooling. Key specifications include a continuous standstill torque of 28.0 Nm, rated speed of 2800 rpm, and maximum speed of 4500 rpm. The motor’s encoder provides reliable performance, and the connection is established through an output connector on side B. It is rated IP65 and weighs 34 kg. The design incorporates a thermal time constant of 60 min (surface cooling) and 90 min (natural convection), allowing operation within ambient temperatures of 0 to +45 ºC. Windings inductance is specified at 4.8 mH.

Technical Specifications

Size
112

Windings Code
48

Motor Length
B (28.0 Nm)

Holding Brake
No

Shaft Type
Plain shaft with sealing rings

Feedback System
Resolver

Power Connector Position
Side B

Cooling Mode
Natural

Motor Over-Temperature Range
60K/100K

Characteristic Motor Speed
3500 per minute

Natural Continuous Torque at Standstill
28, 0 Nm

Rated Speed
2800 rpm

Maximum Speed
4500 rpm

Protection Category
IP65

Weight
34 Kgs

Common Misspellings

1620 Old Apex Road
Cary, NC 27513, USA

Toll Free: 1-888-551-3082
International: 1-919-443-0207

Fax: 1-919-867-6204

[email protected]

Shipping & Payment Options

Warranty

Indramat USA 1 Year Warranty

Repair

We offer a repair service for the MKD112B-048-GG0-BN.

Exchange

Want to sell your MKD112B-048-GG0-BN?
