R911275472 (MKD112C-058-GG2-BN)

Name: R911275472 (MKD112C-058-GG2-BN)
Brand: Indramat Motors
SKU: MKD112C-058-GG2-BN
Price: 813.00 USD
Availability: InStock

MKD Synchronous Motors

Front Left

In-Stock, Ships 3-5 Days

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone

Part Number

+Add a message

Message

Request a Replacement

Request a Repair

Quote Both

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Current response time:

4 Minutes 12 Seconds

Phone:
1-888-551-3082

Email:
sales@indramat-usa.com

The R911275472 (MKD112C-058-GG2-BN) is a Rexroth Indramat synchronous servo motor engineered for industrial kinetic energy applications. It features a rated current of 43 A, a maximum speed of 4000 min⁻¹, and a peak current of 239 A. The unit provides a continuous standstill torque of 38.0 Nm and a maximum torque output of 75 Nm. Physical dimensions are 526 mm in length and 192 mm in width, with a total weight of 32 kg. The motor integrates resolver feedback (RSF) for position detection and includes an incremental encoder with 2048 lines. Additional features include a plain shaft design with shaft seal, a 50 Nm holding brake, internal blower cooling, and an output connection type. The motor is finished with a black prime coat for protection against liquids and acids, and the mounting configuration is IM B5.

Technical Specifications

Type
Industrial AC motor

Maximum speed
4000min-1

Peak current
239Amperes

Length
526 millimetres

Width
192 millimetres

Connection box orientation
Facing side B of motor

Holding brake torque
50 Newton-meters

Cooling method
Internal air blower

Optional sealing
Sealing air connecter for overpressure in housing

Rated current
43 Amperes

Rated voltage
276 volts

Global shipping
Yes

Frequently Asked Questions

What encoder type does the MKD112C-058-GG2-BN support?

The MKD112C-058-GG2-BN supports an incremental encoder, ensuring highly precise position tracking for tight motion synchronization.

Does the MKD112C-058-GG2-BN come with an integrated brake?

Yes, the MKD112C-058-GG2-BN features a built-in holding brake that protects users and system equipment by preventing the motor from moving accidentally when it is turned OFF.

What operating temperature supports optimal performance for the MKD112C-058-GG2-BN?

The MKD112C-058-GG2-BN has a broad temperature tolerance that allows it to maintain ideal performance between 0 °C and +45°C.

What is the mass of the MKD112C-058-GG2-BN motor?

The MKD112C-058-GG2-BN has a mass of 32 kg that enables it to remain stable during operation while maintaining a moderate construction that is easy to integrate.

How does the MKD112C-058-GG2-BN facilitate efficient coupling?

The MKD112C-058-GG2-BN facilitates efficient coupling by providing a smooth shaft for attaching to other components. This creates friction-free connections that enable robust power delivery for smooth system performance.

Common Misspellings

MKD112C058GG2BN

MKD112C 058 GG2 BN

mkd112c-058-gg2-bn

Internal Product Review

The MKD112C-058-GG2-BN is a practical motor with a host of features that simplify operation. Its built-in encoder eliminates the need for external feedback. Keeping setup costs and complexity minimal. However, for proper operation, the motor should be installed with adequate ventilation for thermal stability.
