R911277500 (MKD112B-024-KG0-RN)

Name: R911277500 (MKD112B-024-KG0-RN)
Brand: Indramat Motors
SKU: MKD112B-024-KG0-RN
Price: 844.00 USD
Availability: InStock

MKD Synchronous Motors

Front Left

In-Stock, Ships 3-5 Days

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone

Part Number

+Add a message

Message

Request a Replacement

Request a Repair

Quote Both

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone:
1-888-551-3082

Email:
sales@indramat-usa.com

The Bosch Rexroth servo motor R911277500 (MKD112B-024-KG0-RN) is part of the MKD series and is designed for use with intelligent drive control systems. It features electronic commutation, allowing for precise high-speed start-stop operations. This synchronous servo motor is equipped with a resolver feedback system with integrated encoder, supporting absolute position detection above 4096 revolutions. It delivers a peak torque of 86 Nm, with continuous standstill torque rated at 28 Nm, and operates at a rated speed of 3000 rpm (233 Hz). The motor utilizes a plain shaft with a shaft seal, does not include a holding brake, and has IP65 protection. The unit is cooled by natural convection, has four pole pairs, a flange size of 192 mm, a motor size of 112, and weighs 34 kg.

Technical Specifications

Type
Servo Motor

Integration
Drive Controller Compatible

Primary use
High Speed Start-Stop Operations

Motor Design
Electronic Commutations

Maximum Torque
102 Nm

Cooling Method
Natural Convection

Characteristic Motor Speed
2000 rpm

Maximum Speed
4000 rpm

Torque Constant at 20 ᵒC
1.43 Nm/A

Torque at Standstill (Overtemperature 100 K)
33 Nm

Torque at Standstill (Overtemperature 60 K)
28 Nm

Mass
34 kg

Pole Pairs
4

Rated Speed
3000 rpm

Rated Frequency
233 Hz

Installation Altitude
1000 meters above sea level

Bearings
Grease Lubricated

Industries Served
Packaging Materials, Printing, Woodworking

Global Shipping
Available

Frequently Asked Questions

What is the maximum torque generated by the MKD112B-024-KG0-RN in peak load conditions?

The MKD112B-024-KG0-RN generates a peak torque of MKD112B-024-KG0-RN, ensuring that the motor does not suffer performance loss under peak loads.

What is the permissible range for operating the MKD112B-024-KG0-RN?

The MKD112B-024-KG0-RN is designed to be operated in moderate ambient conditions that fall within a 0 to +45 degrees Celsius range.

What type of shaft delivers output in the MKD112B-024-KG0-RN?

The MKD112B-024-KG0-RN comes with a plain shaft type to deliver output efficiently to the connected machinery, ensuring minimal friction and oscillations during operation.

Is the MKD112B-024-KG0-RN suited for foot mounting?

No, the MKD112B-024-KG0-RN features an IM B5 design that indicates a flange-mount construction that supports installation using the motor's flange interface.

What type of postion feedback is available with the MKD112B-024-KG0-RN?

The MKD112B-024-KG0-RN offers high-accuracy position feedback facilitated by an integrated multiturn encoder that provides exact data on the position of the shaft in real-time.

Common Misspellings

MKD112B024KG0RN

MKD112B 024 KG0 RN

mkd112b-024-kg0-rn

Internal Product Review

The MKD112B-024-KG0-RN offers a user-friendly option with a practical design that incorporates efficient motor feedback. While the enclosure protection is well-suited for harsh environments, users should note that the operating temperature should not exceed +45 degrees Celsius.
