R911284525 (MKD112C-058-KG0-AN)

Name: R911284525 (MKD112C-058-KG0-AN)
Brand: Indramat Motors
SKU: MKD112C-058-KG0-AN
Price: 609.00 USD
Availability: InStock

MKD Synchronous Motors

Front Left

In-Stock, Ships 3-5 Days

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone

Part Number

+Add a message

Message

Request a Replacement

Request a Repair

Quote Both

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Current response time:

6 Minutes 49 Seconds

Phone:
1-888-551-3082

Email:
sales@indramat-usa.com

The R911284525 (MKD112C-058-KG0-AN) is a synchronous AC servo motor from the Bosch Rexroth MKD series, configured with a plain shaft and shaft seal. This motor features a 192 mm flange, 130 mm centering diameter, and output connector on side A. It is equipped with resolver feedback and an integrated multiturn absolute encoder for position detection over more than 4096 revolutions. Specification highlights include a continuous torque at standstill of 38.0 Nm, rated speed of 3000 RPM, maximum speed of 4000 RPM, peak torque of 148 Nm, a rotor inertia of 0.0228 kg·m², and a weight of 22 kg. The unit does not include a holding brake and meets IP65 protection standards.

Technical Specifications

Applications
Packaging machines, Automation, Paper industries

Reliability
High

Performance data
High

Peak Torque Rating
Wide motor speed range

Holding Brake
Not Included (can be ordered separately)

Flange Size
192mm

Centering Diameter
130mm

Shaft Type
Plain shaft with sealing ring

Power Connection
Side A

Insulation Class
F

Weight
45kg

Maximum Speed
4000 RPM

Theoretical peak torque
148 Nm

Rotor Inertia
273 x 10-4 kg m2

Protection Category
IP 65

Maximum setup height
1000 meters

Colour
Prime black

Peak Current
239 Amps

Winding Inductance
1.5 millihenry

Voltage Constant
72.7 V/1000 RPM at 20 degrees Celsius

Permissible Temperature for Storage and Transportation
-20 to 80 degrees Celsius.

Frequently Asked Questions

What supply voltage is required to operate the MKD112C-058-KG0-AN?

The MKD112C-058-KG0-AN operates on 400 V, ensuring stable performance in systems with a compatible voltage range.

What type of thermal management is used in the MKD112C-058-KG0-AN?

The MKD112C-058-KG0-AN is a fanless motor that relies on natural air cooling to maintain stable internal temperatures. Heat is dissipated using ambient air flow, preventing build-up in the motor during continuous use scenarios.

What is the nominal output for the MKD112C-058-KG0-AN?

The MKD112C-058-KG0-AN has a 3.2 kW nominal output that is designed to handle dynamic loads in demanding motion control systems.

What braking options does the MKD112C-058-KG0-AN provide?

The MKD112C-058-KG0-AN is not fitted with a blocking brake, but users can adapt external braking solutions depending on their system requirements.

What mounting option is supported by the MKD112C-058-KG0-AN?

The MKD112C-058-KG0-AN supports flange mounting, ensuring seamless integration into diverse automated setups.

Common Misspellings

MKD112C058KG0AN

MKD112C 058 KG0 AN

mkd112c-058-kg0-an

Internal Product Review

The MKD112C-058-KG0-AN excels in small to medium-duty applications. It comes in a solid construction that keeps vibrations to a minimum during operation. However, some users may find the weight a bit high, especially in smaller layouts.
