R911285765 (MKD112C-024-KP3-AN)

How does the resolver feedback with integrated absolute (>4096 rev) detection enhance commissioning repeatability on MKD112C-024-KP3-AN?

The resolver provides rugged sinusoidal position tracking while the integrated absolute encoder preserves multi-turn position across cycles to minimize homing time and cumulative indexing error. Its combination accelerates start-ups and improves synchronous axis alignment in multi-axis packaging or press applications.

Why specify a 70 Nm holding brake on MKD112C-024-KP3-AN for vertical or interrupted-motion axes?

The brake supplies static torque to prevent back-driving under gravity or shock for protecting tooling and fixtures during E-stops. It also stabilizes fixture position during metrology moves to reduce servo dither and thermomechanical drift.

What is the implication of the torque constant (kt ≈ 1.05 Nm/A) for drive sizing and thermal headroom?

The higher kt yields commanded torque at lower phase current for easing inverter RMS demand and copper losses. It simplifies current-loop tuning while preserving thermal margin under natural-convection cooling at mid-band speeds.

What role does the keyed shaft and shaft seal play in driveline integrity for MKD112C-024-KP3-AN?

The keyed interface transmits torque without fretting typical of purely frictional hubs to improve phase accuracy in cyclic loads. Its seal mitigates ingress of aerosols and fines for maintaining lubrication and encoder cleanliness in packaging and printing environments.

How does absolute multi-turn referencing on MKD112C-024-KP3-AN reduce cumulative registration error in multi-station lines?

The absolute position persists across power cycles, each station reacquires exact angular phase without homing traversals. It preserves print/register alignment and cut-to-mark accuracy over repeated starts.

MKD 112C-024-KP3-AN

MKD-112C-024-KP3-AN

MKD112C-O24-KP3-AN

MKD112C024KP3AN

MKD112C 024 KP3 AN

mkd112c-024-kp3-an

The Rexroth Indramat’s MKD112C-024-KP3-AN servo motor comes with a keyed design of shaft that has a sealing ring as well. It is equipped with a 70 Nm holding brake and it possess a resolver/absolute multi-turn feedback. This AC motor uses natural-convection surface cooling. It delivers a rated torque of 24 Nm and consumes 7.3 kW of power. Due to its precise position retention and reliable stall torque, it suits packaging lines, machine tools and printing/textile equipment.
