R911285980 (MKD112B-048-GP0-LN)

MKD Synchronous Motors

Rated 4 stars (9 total reviews)
  In Stock, Ships 2-3 Days
Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping
Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping
The synchronous motor R911285980 (MKD112B-048-GP0-LN) is part of the MKD series by Rexroth Bosch Indramat and features a 112 mm frame size with flange size of 192 mm and motor length B. It delivers a continuous standstill torque of 28.0 Nm and supports a rated current of 22.4 A, with maximum current up to 60.8 A. The unit operates in ambient temperatures from 0 to 40°C and employs standard cooling (LN). It includes a keyed shaft (DIN 6885-1) with shaft seal, left-side connection direction, three-phase operation, and IP65 enclosure. Relative position detection is handled by resolver feedback (RSF); the motor is supplied without a holding brake.

Technical Specifications

Classification
112

Motor Length
B

Class Torque
28.0 Nm

Rated Torque
7.7 Nm-18.1 Nm

Power Rating
2.7 kW-6.7 kW

Motor Size
48

Rated Speed
2,800 RPM

Maximum Speed
4500 RPM

Shaft Details
With key per DIN 6885-1

Shaft Sealing Rings
Yes

Holding Brake
No

Operating Temperature Range
0 to 40 degree C

Heat Dissipation
Surface of the housing

Motor Feedback System
Integrated resolver

Weight
34 Kg

Output Power Connection
Left side

Common Misspellings

Shipping & Payment Options
DHL-logo FexEd-logo UPS-logo freight-icon

AmEx-icon Mastercard-icon Visa-icon wire-transfer-icon
Warranty
1-year-warranty
Indramat USA 1 Year Warranty
Repair
We offer a repair service for the MKD112B-048-GP0-LN.
