R911286174 (MKD112B-058-KG0-BN)

Name: R911286174 (MKD112B-058-KG0-BN)
Brand: Indramat Motors
SKU: MKD112B-058-KG0-BN
Price: 672.00 USD
Availability: InStock
Rating: 4.4 (6 reviews)

MKD Synchronous Motors

Rated 4.4 stars (6 total reviews)

Front Left

In-Stock, Ships 3-5 Days

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone

Part Number

+Add a message

Message

Request a Replacement

Request a Repair

Quote Both

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone:
1-888-551-3082

Email:
sales@indramat-usa.com

The R911286174 (MKD112B-058-KG0-BN) is a servo motor engineered for precise speed, torque, and position control in industrial automation applications. Featuring a plain shaft with shaft seal, natural convection cooling, and robust bearings for significant radial loads, it offers stable operation in demanding environments. The unit is rated for 8.1 kW power, 400V voltage, and delivers a continuous standstill torque of 28.0 Nm. It employs electronic commutation with resolver feedback and integrated encoder for absolute position detection beyond 4096 revolutions. The motor size is 112 with a B-length configuration and 130 mm centering diameter. Protection class is IP65 and it operates in humidity up to 95%, non-condensing. Output connections are provided by an output connector; it is supplied without a holding brake or other special designs.

Technical Specifications

Product Line
Servo Motors

Commutation Type
Electronic

Design Feature
Low Inertia

Maximum Overtemperature
100 K

Rated Torque
11.9 Nm

Standstill Torque
28 Nm

Capability
High Frequency Start-Stop Movements

Functional Settings
Variety of Industrial Settings

Ambient Condition Resilience
High

Radial Loads Sustenance
High due to Quality Bearings

Global Shipping
Yes

Brush Type
No Brush (Electronic Commutation)

Constant Torque Output Capability
At Varying Speeds

Frequently Asked Questions

Which supply pairing fits MKD112B-058-KG0-BN drive selection?

It operates at 400V. Aligning inverter and cabling to this level preserves modulation headroom and current margin so torque production remains efficient under dynamic profiles.

What continuous mechanical benchmark guides duty sizing on MKD112B-058-KG0-BN?

It provides 42 Nm torque. The rating informs gear selection and feed rates, keeping thermal rise and component wear within expected limits.

What ambient moisture tolerance affects site planning for MKD112B-058-KG0-BN?

It supports 0 to 95% non-condensing humidity. This range informs enclosure decisions and helps maintain insulation and terminal integrity in variable climates.

Why does MKD112B-058-KG0-BN skip homing after power restoration?

It offers absolute (>4096 revs) position detection. Coordinates persist, enabling immediate motion and protecting timing among synchronized axes.

What coupling option fits varied drivetrains on MKD112B-058-KG0-BN?

It features a plain shaft. The journal supports diverse hub choices, allowing stiffness and backlash to be matched to the mechanical system.

Common Misspellings

MKD 112B-058-KG0-BN

MKD-112B-058-KG0-BN

MKD112B-O58-KGO-BN

MKD112B058KG0BN

MKD112B 058 KG0 BN

mkd112b-058-kg0-bn

Internal Product Review

Indramat's MKD112B-058-KG0-BN is engineered for sealed simplicity and immediate start readiness. Its natural convection avoids fan wear and dust ingestion. Its standardized geometry speeds installation, making it one of the most efficient models in the market.
