R911286568 (MKD112C-024-GP0-LN)
MKD Synchronous Motors
Technical Specifications
Product
Bosch Rexroth Synchronous Motor
Rated Voltage
372/404 V
Operating Frequency
167 Hz
Frame Size
112
Flange Size
192 mm
Centering Diameter
130 mm
Constant Torque
1.6 Nm/A at 20 degree Celsius
Motor Winding Resistance
0.44 Ohm
Holding Brake
No
Output shaft balance
With full key
Continuous Power
5.2 – 14.1 kW at 2500 rpm
Cooling Method
Ambient air, optional blower
Housing
Prime Coat Black
Protection Category
IP 65
Max Operation Temp without derating
+40 degree Celsius
Position Detection
Digital Resolver Feedback
Insulation Class
F
Frequently Asked Questions
Why are the 192 mm flange and Ø130 mm centering diameter on MKD112C-024-GP0-LN advantageous for stiffness and coaxiality in precision mounts?
The larger pilot distributes radial load and constrains runout for reducing coupling misalignment forces and bearing preload in high-speed duty. It improves repeatable installation geometry when swapping motors on precision tool spindles or converting packaging axes.
What are the control-loop consequences of the 0.014 kg·m² rotor inertia when MKD112C-024-GP0-LN is coupled to a low-inertia web feed or pick-and-place axis?
Its low reflected inertia ratios of <3:1 allow higher velocity-loop bandwidth without exciting torsional modes that enables aggressive jerk-limited profiles.
How is the 38.0 Nm continuous torque at standstill used on MKD112C-024-GP0-LN despite the absence of a holding brake?
The drive commands DC torque via current regulation to counter static loads; thermal models must keep copper and magnet temperatures within limits. For vertical axes, pair with a spring-applied, electrically released machine-side brake for fail-safe parking.
How do the 27.7 A rated current and 11.7 kW rating of MKD112C-024-GP0-LN shape drive sizing and cabling?
The controller with resolver interface whose continuous current exceeds 27.7 A with headroom for overload; conductor cross-section and connector thermal rating must match expected RMS current. It is to also verify DC-link voltage and back-EMF margin at 5,000 RPM operating points.
What ingress protection is typical for MKD112C geometry with a shaft seal, and how should designers confirm IP compliance?
The MKD112C variants achieve IP65 when equipped with a shaft seal and appropriate connectors; verify against the exact code and nameplate. Confirm sealing compatibility with washdown or oil-mist exposure if applicable to the process.
Common Misspellings
MKD 112C-024-GP0-LN
MKD-112C-024-GP0-LN
MKD112C-O24-GPO-LN
MKD112C024GP0LN
MKD112C 024 GP0 LN
mkd112c-024-gp0-ln
Internal Product Review
The Rexroth Indramat’s MKD112C-024-GP0-LN servo motor integrates a 192 mm flange and it comes with a sealed keyed shaft. It relies on RSF resolver for relative position feedback. This unit is rated for 11.7 kW and offers 38 Nm torque at standstill. It is designed for 5000 RPM and draws 27.7 A, while it is widely usedacross machine tools, packaging lines and printing systems.
