R911289713 (MKD112C-058-GG0-LN)

Name: R911289713 (MKD112C-058-GG0-LN)
Brand: Indramat Motors
SKU: MKD112C-058-GG0-LN
Price: 436.00 USD
Availability: InStock

MKD Synchronous Motors

Front Left

In-Stock, Ships 3-5 Days

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone

Part Number

+Add a message

Message

Request a Replacement

Request a Repair

Quote Both

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone:
1-888-551-3082

Email:
sales@indramat-usa.com

The R911289713 (MKD112C-058-GG0-LN) is a Rexroth Indramat servo motor engineered for industrial automation, compatible with drive controller series such as HDS, HDD, and DKS. This motor supports motor feedback via resolver feedback (RSF), enabling relative position detection for precision control. It features a plain shaft with shaft sealing, operates without a holding brake, and is designed with motor size 112 and length C, centering diameter 130 mm. Electrical connection is achieved through a rotatable terminal box on the left side. Technical ratings include a rated current of 43 A, voltage requirement of 276 V, continuous standstill torque of 38.0 Nm, nominal torque of 60 Nm, maximum torque of 135 Nm, and output power of 19.4 kW. The unit utilizes liquid cooling and meets IP65 protection standards. The maximum leakage current exceeds 3.5 mA, necessitating effective grounding. Ancillary components such as electrical cables, blower units, sealing air connectors, and planetary gearings must be selected based on operational requirements. Motor performance depends on ambient temperature and installation elevation.

Technical Specifications

Type
Industrial Motor

Feature
Motor Feedback System

Encoder
Converts physical movement to digital signals

Load Capacity
High Radial Loads

Leakage Current
Exceeds 3.5 milliamperes

Rated Current
43 Amperes

Rated Torque
43.5 Newton meters

Rated Power
19.4 Kilowatts

Rated Voltage
276 Volts

Battery Type
Internal, Holds Information When Turned Off

Shipping Information
Global

Frequently Asked Questions

What is the rated current consumption for the MKD112C-058-GG0-LN?

The MKD112C-058-GG0-LN operates with a 16.3 A current consumption, ensuring sufficient capacity for high power demands.

What is the peak speed that the MKD112C-058-GG0-LN can provide?

The peak speed performance for the MKD112C-058-GG0-LN is 6800 rpm, ensuring fast and efficient performance in high-throughput applications.

Is the MKD112C-058-GG0-LN easy to integrate?

Yes, the MKD112C-058-GG0-LN is a moderate-sized motor with a flange-mount design that makes it easy to integrate into a wide range of system designs.

What connection options does the MKD112C-058-GG0-LN offer for power cables?

The MKD112C-058-GG0-LN offers a left-side power connection, ensuring streamlined electrical integration for quick and efficient setup.

Is the output shaft on the MKD112C-058-GG0-LN equipped with a seal?

Yes, the MKD112C-058-GG0-LN comes with a plain shaft interface that includes a sealing ring to protect the motor from contaminants during operation.

Common Misspellings

MKD112C058GG0LN

MKD112C 058 GG0 LN

mkd112c-058-gg0-ln

Internal Product Review

The MKD112C-058-GG0-LN offers outstanding reliability in challenging environments. Its dust and moisture resistance keeps performance consistent even when exposed to dust or other contaminants. However, the limited installation flexibility can complicate setup in some systems.
