R911292003 (MKD112C-024-KG3-LN)

Name: R911292003 (MKD112C-024-KG3-LN)
Brand: Indramat Motors
SKU: MKD112C-024-KG3-LN
Price: 315.00 USD
Availability: InStock

MKD Synchronous Motors

Front Left

In-Stock, Ships 3-5 Days

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone

Part Number

+Add a message

Message

Request a Replacement

Request a Repair

Quote Both

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone:
1-888-551-3082

Email:
sales@indramat-usa.com

The Bosch Rexroth synchronous motor R911292003 (MKD112C-024-KG3-LN) is designed for use with intelligent drive controllers as a servo or main spindle drive in automation and handling systems. It operates from a 400 V AC supply at a rated frequency of 167 Hz, providing a rated torque of 77 Nm and achieving nominal speed at 2500 rpm, with a maximum speed of 4500 rpm. The motor features a plain output shaft with shaft sealing rings, digital servo feedback with a multi-turn absolute encoder, and a 70 Nm holding brake. The housing is rated IP65, uses natural air cooling, weighs 45 kg (without blower), and supports operation at up to 40°C and 1000 m altitude.

Technical Specifications

Product Type
Synchronous Motor

Use
Servo and Main Spindle Drive Motor

AC Supply Voltage
372 - 404 V

Rated Frequency
167 Hz

Power
5.2 - 14.1 kW

Nominal Speed
2500 rpm

Cooling Method
Natural Air and Surface Cooling

Winding Code
024

Resistance
0.44 Ohm at 20 degree Celsius

Housing
Prime Black Coat

Protection Rating
IP65

Maximum Speed
4500 rpm

Output Shaft
Plain with Shaft Sealing Rings

Digital Servo Feedback
Integrated with Multi-Turn Absolute Encoder

Holding Brake
70 Nm

Power Connector Location
Top with Left Output

Weight
45 kg

Maximum Operating Temperature
40 degree Celsius

Maximum Operating Altitude
1000 meters above sea level

Frequently Asked Questions

What input voltage does the MKD112C-024-KG3-AN support?

The MKD112C-024-KG3-AN supports 400 V input, providing broad compatibility with power setups in industrial settings.

What is the rated current input for the MKD112C-024-KG3-AN?

The MKD112C-024-KG3-AN operates on a nominal current of 26.3 A, enabling robust but energy-efficient operation.

What type of shaft is the MKD112C-024-KG3-AN fitted with?

The MKD112C-024-KG3-AN has a plain shaft that provides reliable torque output with smooth rotations for enhanced system reliability.

What is the mechanical output capacity for the MKD112C-024-KG3-AN?

The MKD112C-024-KG3-AN provides a mechanical output of 12 kW for efficient handling of varied load conditions.

What is the maximum torque that the MKD112C-024-KG3-AN can provide?

The MKD112C-024-KG3-AN is rated for a maximum torque of 231 Nm, ensuring that the motor can handle peak loads without performance degradation.

Common Misspellings

MKD112C024KG3LN

MKD112C 024 KG3 LN

mkd112c-024-kg3-ln

Internal Product Review

The MKD112C-024-KG3-AN excels in systems that require tight motion profiles. It comes with integral feedback eliminating the need for external solutions. However, the C-sized frame might be too bulky for very tight setups.
