R911297407 (MKD112A-058-KG0-BN)

Name: R911297407 (MKD112A-058-KG0-BN)
Brand: Indramat Motors
SKU: MKD112A-058-KG0-BN
Price: 876.00 USD
Availability: InStock
Rating: 4.1 (5 reviews)

MKD Synchronous Motors

Rated 4.1 stars (5 total reviews)

Front Left

In-Stock, Ships 3-5 Days

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone

Part Number

+Add a message

Message

Request a Replacement

Request a Repair

Quote Both

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Current response time:

6 Minutes 47 Seconds

Phone:
1-888-551-3082

Email:
sales@indramat-usa.com

The R911297407 (MKD112A-058-KG0-BN) is a Bosch Rexroth Indramat synchronous AC servo motor with a plain shaft design and shaft seal. It features a windings code of 058, a continuous standstill torque of 15.0 Nm, and a moment of inertia of 0.012 kgm². The motor has a connecting flange diameter of 192 mm and a centering diameter of 130 mm, with a rated speed up to 3000 RPM and a theoretical max speed of 4500 RPM. It utilizes resolver feedback with an integrated multiturn-absolute encoder (absolute position detection >4096 revolutions). The motor operates at 315 V with a three-phase connection via output connector and does not include a holding brake. Housed according to IP65 standards, it is resistant to dust, shock, and water jets. Lifetime-lubricated gearings use the planetary wheel principle. The unit incorporates a standardized drive controller connection and a temperature sensor for monitoring.

Technical Specifications

Windings Code
058

Weight
23 kg

Power Connector
Side B

Maximum Speed
4500 rpm

Characteristic Speed
4000 rpm

Motor Type
Shaft Driven

Shaft Sealing Ring
Present

Rated Speed
3500 rpm

Frequency Rating
233 Hz

Commutation
Electrical

Product Feature
Continuous start-stop operation

Product Classification
IP65 protection class

Insulation Class
F

Connecting Flange Size
192 mm

Shaft Diameter
130 mm

Motor Design
Standard

Holding Brake
Not available

Gearing Lubrication
Lifetime

Gearing Principle
Planetary wheel

Design
Compact

Connections
Standardized electric

Temperature Sensor
Present

Frequently Asked Questions

How does voltage capability affect MKD112A-058-KG0-BN?

It handles up to 460 V. This aligns with common industrial mains supplies, allowing installation without requiring dedicated step-up or step-down electrical conversions.

How does feedback method assist MKD112A-058-KG0-BN?

It provides absolute position detection beyond 4096 revolutions. Systems restart without homing, improving recovery after power interruptions.

Why is plain shaft design important in MKD112A-058-KG0-BN?

It uses a plain shaft, enabling clamp hubs or zero-backlash couplers. This makes integration flexible across various mechanical configurations.

How does cooling design support MKD112A-058-KG0-BN?

It employs standard cooling through its frame. This ensures heat dissipates naturally, minimizing reliance on external fans or ducts.

What power scheme applies to MKD112A-058-KG0-BN?

It operates on three phases. This matches industrial inverters and reduces imbalance issues in high-torque applications.

Common Misspellings

MKD 112A-058-KG0-BN

MKD-112A-058-KG0-BN

MKD112A-O58-KGO-BN

MKD112A058KG0BN

MKD112A 058 KG0 BN

mkd112a-058-kg0-bn

Internal Product Review

Bosch Rexroth's MKD112A-058-KG0-BN ensures steady motion with a plain shaft suited to flexible coupling systems. Its structure balances resilience and adaptability, thus sustaining accuracy under varying conditions.
