R911297678 (MKD112C-024-KP0-LN)

Name: R911297678 (MKD112C-024-KP0-LN)
Brand: Indramat Motors
SKU: MKD112C-024-KP0-LN
Price: 346.00 USD
Availability: InStock

MKD Synchronous Motors

Front Left

In-Stock, Ships 3-5 Days

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone

Part Number

+Add a message

Message

Request a Replacement

Request a Repair

Quote Both

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Current response time:

3 Minutes 24 Seconds

Phone:
1-888-551-3082

Email:
sales@indramat-usa.com

The R911297678 (MKD112C-024-KP0-LN) is a Bosch Rexroth synchronous servo motor from the MKD family, featuring four pole pairs and designed for use with GTS or GTP series planetary gears. It incorporates a power connector with brake and temperature sensor interfaces located on the left side, and utilizes a resolver feedback encoder for absolute position detection exceeding 4096 revolutions. The motor has a shaft with keyway and chemical-resistant, oil-resistant design per DIN 3760, with a flange size of 192 mm, centering diameter of 130 mm, and a nominal speed of 2000 RPM. Continuous torque at standstill is 38.0 Nm. The configuration does not include a holding brake, and the unit requires separate procurement of connection cables and plugs. The motor weighs 24 kg, supports installation in any position up to 1,000 m altitude, operates under natural convection cooling, and is coated in RAL 9005 black. Shock-decoupled load use is required, and heavy reversing loads may affect shaft integrity.

Technical Specifications

Encoder Connection
Available

Power Connector
Available

Additional Connections
Holding brake, Temperature sensor

Pole Pairs
Four

Power Connector Output Direction
Left side

Cooling System Connectivity
Three-core connection cable (0.75mm2)

Device Installation
Any position

Motor Shaft Materials
Chemical and oil resistant

Radial Shaft Sealing Ring Design
Based on DIN 3760 specifications

Axial and Radial Forces
Subject to during operation

Winding Inductance
6.7mH

Rated Frequency
167Hz

Bearings Service Life
30,000 hours as per ISO 281

Motor Color
RAL 9005 Black prime coat

Gear Teeth Features
Low-play and high torsional strength

Operating Height
Up to 1,000m above sea level

Load Carrying Capability
Only if they are shock-decoupled

Motor Positioning
Installable in any position

Frequently Asked Questions

What torque capacity does the MKD112C-024-KP0-LN provide?

The MKD112C-024-KP0-LN has a 38.0 Nm rated torque, enabling it to efficiently handle varied load scenarios in motion control tasks.

Does the MKD112C-024-KP0-LN require external feedback?

No, in the MKD112C-024-KP0-LN motor, the resolver feedback is built into the motor, eliminating the need for external feedback solutions.

What is the size of the MKD112C-024-KP0-LN motor?

The MKD112C-024-KP0-LN is a size 112 motor with a frame of C length. This indicates a moderate build that offers enhanced torque density without being too bulky.

Does the MKD112C-024-KP0-LN feature a smooth output shaft?

No, the shaft design on the MKD112C-024-KP0-LN includes a keyway that allows mechanical integration with key balancing for even load distribution when coupling with other components.

What environmental sealing standards does the MKD112C-024-KP0-LN meet?

The MKD112C-024-KP0-LN meets IP65 standards for environmental protection, ensuring that the motor can operate safely even in harsh environments.

Common Misspellings

MKD112C024KP0LN

MKD112C 024 KP0 LN

mkd112c-024-kp0-ln

Internal Product Review

The MKD112C-024-KP0-LN delivers versatile performance in systems that require enhanced torque performance. It can handle high loads effectively. However, the lack of a holding brake can be limiting in applications that require vertical lifting or position holding.
