The R911297804 (MKD112A-058-KG0-AN) is a Bosch Rexroth synchronous AC servo motor from the MKD series, featuring size 112, motor length A, and a 130 mm centering diameter. It operates with a rated speed of 3500 min-1 and maximum speed of 4500 min-1, delivering a continuous standstill torque of 15.0 Nm and rated torque of 29 Nm. The motor supports self-cooling, has a plain shaft with sealing ring, and is constructed with IP65 protection class for enhanced resistance to dust and water. Resolver feedback with integrated encoder enables absolute position detection exceeding 4096 revolutions per DIN 42948 standard. Maximum current is 77 A, thermal time constant is 40 minutes, flange size is 192 mm, and connection is on Side A.

Technical Specifications

Motor Type
Synchronous AC Motor

Characteristic Speed
4000 min-1

Motor Size
112

Motor Length
B

Weight
23 kg

Pole Pairs
4

Peak Current Rating
77 A

Rated Speed
3500 min-1

Maximum Speed
4500 min-1

Thermal Time Constant
40 Minutes

Min Strand Cross-Section
1.5 mm2

Feedback
Electromagnetic Transducer (Resolver)

Design
Without Holding Brake

Electrical Commutation
Available

Enclosure
100 %, IP 65 Protection

Driven Shaft
Plain With Sealing Ring

Installation Position
Any

Insulation Class
F

Torque Constant (at 20 C)
0.98 Nm/A

Winding Resistance
0.86 Ohms (at 20 C)

Winding Inductance
7.8 mH.

Frequently Asked Questions

How much output does the MKD112A-058-KG0-AN deliver under nominal conditions?

The MKD112A-058-KG0-AN delivers 7.8 kW output under standard loads, ensuring robust performance in a wide range of motion control systems.

What is the velocity specification for the MKD112A-058-KG0-AN?

The MKD112A-058-KG0-AN has a rated velocity of 3000 min-1, ensuring reliable delivery of speed and torque for optimized motion profiles.

What type of cooling is integrated into the MKD112A-058-KG0-AN?

The MKD112A-058-KG0-AN integrates natural convection cooling, ensuring that the heat in the motor is dissipated outside using natural airflow to maintain thermal stability during operation.

What operating temperatures support ideal MKD112A-058-KG0-AN motor performance?

The MKD112A-058-KG0-AN functions reliably when the temperature range is within 0°C to +45°C, enabling optimal performance in standard environments.

What is the weight of the MKD112A-058-KG0-AN motor?

The MKD112A-058-KG0-AN has a total mass of 34.0 kg, ensuring solid construction for optimal operation stability.

Common Misspellings

MKD112A058KG0AN

MKD112A 058 KG0 AN

mkd112a-058-kg0-an

Internal Product Review

The MKD112A-058-KG0-AN delivers superior performance with excellent speed reliability. Its sturdy construction enhances performance stability across automation environments. However, proper ventilation should be ensured during installation to promote ambient airflow.
