R911310730 (MKD112C-024-GP3-LN)

Name: R911310730 (MKD112C-024-GP3-LN)
Brand: Indramat Motors
SKU: MKD112C-024-GP3-LN
Price: 686.00 USD
Availability: InStock

MKD Synchronous Motors

Front Left

In-Stock, Ships 3-5 Days

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone

Part Number

+Add a message

Message

Request a Replacement

Request a Repair

Quote Both

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Current response time:

4 Minutes 4 Seconds

Phone:
1-888-551-3082

Email:
sales@indramat-usa.com

The R911310730 (MKD112C-024-GP3-LN) is an industrial AC servo motor engineered by Rexroth Indramat, suitable for precision applications in automated systems. It has a size of 526 mm x 192 mm, a rated speed of 3000 rpm, and supports a maximum speed up to 4500 min⁻¹. The motor provides a continuous torque of 38.0 Nm at standstill and a maximum torque of 78 Nm. It includes a shaft with keyway, shaft seal, electric holding brake rated at 70 Nm, and a resolver (RSF) for relative position feedback. The housing features a 130 mm centering diameter and insulation class F. Protection against dust and jet water is provided, and total mass is approximately 45 kg.

Technical Specifications

Length
526 mm

Width
192 mm

Rotation Speed
4500min-1

Torque
148 newton-meters

Bearing Type
Grease-lubricated

Penetration protection
Resistant to solid materials and jet water

Water Resistance
Not operable Underwater

Rated Current
21.8 Amperes

Rated Voltage
404 Volts

Connection Cable
Three-core, 0.75mm square cross-sectional area

Holding Brake
70-newton meters

External Coating
Prime Black Coat

Weight
45 kilograms

Pole Pair
Four

Insulation Class
F according to DIN VDE 0530 Part 1

Winding Inductance
1.5 millihenry

Voltage Constant at 20 DEG C
72.7 volts per 1000min-1

Torque Constant at 20 DEG C
0.8 newton meters per Ampere.

Frequently Asked Questions

What speed capacity does the MKD112C-024-GP3-LN feature?

The MKD112C-024-GP3-LN has a speed capacity of 3000 rpm that provides enhanced motion stability while maintaining reliable torque delivery.

Is the MKD112C-024-GP3-LN fan-cooled?

No, the MKD112C-024-GP3-LN operates without a fan since its built-in natural cooling is efficient in dissipating heat and maintaining stable thermal performance.

Which flange configuration does the MKD112C-024-GP3-LN feature?

The MKD112C-024-GP3-LN features a keyway shaft that is optimized for high-load applications that require secure mechanical coupling to allow secure transmission of output power.

Does the MKD112C-024-GP3-LN support foot mounting?

No, the MKD112C-024-GP3-LN is built to be installed via a flange, allowing streamlined integration into different setups.

What type of brake does the MKD112C-024-GP3-LN come with?

The MKD112C-024-GP3-LN comes with a heavy-duty brake that features a torque capacity of 70 Nm.

Common Misspellings

MKD112C024GP3LN

MKD112C 024 GP3 LN

mkd112c-024-gp3-ln

Internal Product Review

The MKD112C-024-GP3-LN offers high-torque performance ideal for demanding applications. Its speed performance is adaptable to diverse system demands. However, the weight can require additional mounting consideration in smaller setups.
